| ELECTRICAL SPECIFICATION | |||
| Nominal Voltage | 48V | ||
| Nominal Capacity | 60AH | ||
| Stored Energy | 2880Wh | ||
| Self Discharge Rate | Maximum Continous Charge Current | 30A | |
| Maximum Continous Discharge Current | 60A | ||
| Charge Cut-off Voltage | 54V | ||
| Discharge Cut-off Voltage | 37.5V | ||
| Cycle life(25°C) | >1000 times@80%DOD | ||
| MECHANICAL SPECIFICATIONS | |
| Dimensions (mm) | L304×W243×H152 |
| Weight | 16kg around |
| Case Material | SS |
| Enclosure protection | IP54 |
