10t/H~ 100t/H River Water to Daily Drinking Water Treatment Equipment Stainless Steel

Product Description

Products Description

Product name	Seawater Desalination System
Materials	Container, FRP+SS304
Color	Customized
Size	1200*220*230CM
MOQ	1SET

XYD series stainless steel Water purifier is a water purification equipment specially developed by our company for rural drinking Water purification purification. It has 1 invention patent and 50 utility patents to ensure the progressiveness of water purification process and the excellent quality of products.
XYD series stainless steel water purifier is a domestic drinking water purification equipment designed and produced with the core technology of the inner and outer spiral grid coil reactor that has obtained the national invention patent, taking full account of the user's use requirements. It has the characteristics of compact structure, reasonable, simple operation, stable operation, good treatment effect, strong adaptability, etc.
Product Parameters
1. Raw water quality: Raw water turbidity can upto 1500NTU; The quality of other raw water meets the Class I, Class II, and Class III water quality standards in CJ3020-93 "Water Quality Standards for Drinking Water Sources";
2. Effluent water quality: Effluent turbidity ≤ 0.5NTU, and other effluent water quality meets the newly established GB5749-2022 "Hygienic Standards for Drinking Water Quality";
3. Flocculation reaction time: 12-20 minutes;
4. Velocity of steady flow area: 1.38~1.67mm/s;/Liquid surface load in sedimentation area: 5~6m3/m2-h
5. Filtration speed: 6-7 m/h, 7-10 m/h for double-layer combined filter media;
6. Filter pool filter layer height: ≥0.8 meters;
7. Flushing strength: 14~17L/s-m2 (adjustable) with siphon automatic backwashing and manual forced backwashing system;
8. Rinse time: 4~8min (adjustable);
9. Minimum inlet head: 8 meters
Details Images
Process Flow
XYD series water purifier is made of food-grade SUS304 stainless steel plate, which is an optimized combination of water purification processes such as dosing, mixing, coagulation, sedimentation, sludge thickening, filtration, automatic backwashing, disinfection, etc., and it can conveniently purify surface water such as water from reservoirs, mountain streams, or gullies, and rivers, etc. into drinking water that meets the requirements of "Hygienic Standard for Drinking Water for Daily Use" (GB5749-2006).
The core technology of the water purifier---reaction precipitator
1. Our company's flocculation reaction process is based on the core technology of the inner and outer spiral grid coil reactor, which has obtained a national invention patent. The source water added with coagulants enters the inner and outer spiral grid coil channels, and the water flow is a two-way rotating cross flow of the inner and outer layers. The water flow downward along the spiral channel forms a large number of reaction vortices under the combined action of outward centrifugal force and downward gravity, Greatly improving the collision efficiency of particles in the source water, it can quickly form uniform, dense, and easy to precipitate alum flowers. Compared with traditional flocculation reactors, the flocculation reaction efficiency can be increased by about one time, and the dosage of coagulants can be reduced by 20-30% compared to traditional straight plate grid reactors. It also has the advantage of strong impact load resistance, fully solving the problem of reactor layout for circular purification equipment, Especially suitable for factory scale production.
2. The sedimentation process of our reaction precipitator adopts the design of connecting the flocculation reaction and sedimentation area up and down as a whole, utilizing the patented technology of V-shape water flow guide plate to make the rising water flow rate gradually slow down under the joint action of the top support force of the water flow and the alum sinking in the sedimentation area, a floc suspension layer of 300mm or so is formed between the reaction area and the sedimentation area, and the suspended colloidal particles in the water, flocs, bacteria, germs and other impurities will be intercepted in this floc suspension layer, which greatly improves the separation and sedimentation efficiency of alum. The flocculent suspension layer greatly improves the separation and sedimentation efficiency of the alum, ensuring that when the turbidity of the influent water is <=3000NTU, the effluent from the precipitator is less than 10NTU, which reduces the load of the subsequent filters and greatly improves the processing efficiency of the purification equipment. Company Profile Certifications Exhibition Product packaging FAQ A) How could I get a sample? Sample are available, but please afford sample costs and express fee. B) Sample lead time? Existing items: Within 7-10 days. C) Do you offer OEM service and marked our logo on the products? Yes, We offer OEM services. D) What is the delivery time? Normally, delivery time is 20-30days after order. E) How to guarantee the quality of your products? 1) We have strict quality control system, every product has been strictly inspect and stamped QC psssed before shipping out. 2) Strictsampling inspection on products before shipment and intact product packaging ensured.

---
