Hot and Cold Thermal Cycling Testing Machine for Plastic Pipe

Product Description

Plastic Pipe Thermal Cycle Testing Machine

Product Description Plastic Pipe Thermal Cycle Testing Machine is applicable to all kinds of plastic pipes, pipe fittings and pipe systems. Under the condition of pressure and different temperatures within the specified time After completing the test to check the leakage and rupture of pipes and pipe fittings.
Test Standard
ISO1167, ASTM D1598, ASTM D1599, ISO10508 and the equivalent.
Product Specifications

Model	HD-R902
Pressure range	4.00bar-16.00bar, 0.400Mpa-1.600Mpa (Customizable)
Pressure control accuracy	±0.05 Mpa
Number of test stations	6
Alternation time between hot and cold water	< 60s
Cycle period	300s-1200s
Maximum measured cross-sectional area	4200mm² or 6200mm²
Maximum straight pipe length of sample	3700mm
Control mode	PLC control
Display mode	touch screen display
Number of cycles	selectable 1-100000
Temperature range (cold water)	20ºC to RT (selectable) accuracy:±2ºC
Temperature range (hot water)	RT to 95ºC (selectable) accuracy:±1ºC
Temperature display error	1ºC
Temperature uniformity	≤±1ºC
Inlet and outlet temperature difference	2ºC
Power supply	380V±10% 50Hz
Overall dimensions	4500(L)×3000(W)×2000(H)mm(6 stations)
Installation dimension	6000(L)×4000(W)×3000(H)
Optional function	A: Flow measurement and regulation (optional)
	B: Prestress application system (optional)
Model: HD-R902-200A	With Flow measurement and regulation
Model: HD-R902-200B	With Prestress application system
Model: HD-R902-200AB	With Flow measurement and regulation and Prestress application system

About HaidaHaida products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and are applicable to all scientific research units, quality inspection institutions and academic fields. Our products meet ASTM, JIS, GB,SO, TAPPI, EN, DIN, BS and other domestic and international standards.
Why choose us?1.Design & Production : Solution Consultation for each orderRecommend the most cost -performance machineResearch & Develop the suitable one for Special- designed Model.2.Shipping & Delivery: One-Stop ServiceProduction- Deliver to your door - Installation & Training- Technical Support3.Warranty1 year warranty with lifetime technology support4.After-Sale ServiceReact within 2 HoursVideo inspection & on-site service combined

FAQ:
Q:Are your company a trading one or a factory?
A:Factory + trade (integration),More than 12 years focusing on test equipment field,6 years exporting experience.
Q:After an order is placed, when to deliver?
A:Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days.
Please be aware that our production lead times depend on specific items and item quantities.
Q:What about the warranty with after - sales services?
A:The testing machine is guaranteed for 12 months by HAIDA,we can help you to repair
your problem controller freely,even it's not from our factory. After the warranty, the professional after-sale service team will provide perfect technical support and help guests solve problems encountered while using our product, handles guest problems and complaints in a professional and timely.
Q:What about the product' services and quality?
A:Each equiopment must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer's company when you need. products are widely recognized and trusted by users.
A :Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.
Q: Can your products be customized?
A: Yes, our product can be customized according to your parameters.

---
