| US$2,500.00-4,000.00 | 1 Piece (MOQ) |
| Structure | All-metal structure |
| Printing Method | Thermal Transfer Printing |
| Resolution | 300dpi (12 dots/mm) |
| Printing Speed | 40-600mm/s |
| Printing Width | 53mm |
| Print Area | 53mm * 75mm (Intermittent) 53mm * 100mm (Continous) |
| CPU | 32-bit RSIC |
| Flash Memory | 8MB (minimun) |
| Dynamic Memory | 16MB(minumum) |
| Real-time Clock Function | STD (Battery Lifespan: min 3 years) |
| Sensor | Ribbon Tension Detection Thermal Head Position Detection Cover Open Detection TPH over Temperature Detection Ribbon Break Detection |
| Soft Package Detection | Electromagnetic Induction or Synchronizer |
| Soft Package Material | PVDC, PET, PE, NY, CPP, OPP, BOPP, BOPET, BOPA, CPP, PE,VMPET, VMCPP and other films and composite films |
| Capacity for Ribbon Loading | 1 "mandrel with a maximum length of 1100 meters |
| Ribbon Type | Type: Wax / Resin-based width: 20 mm (0.79 ") to 55 mm (2.17") |
| Ribbon Saving | Support interlaced, radial, multiple print signals, digital ribbon saving printing, ribbon back and other ribbon saving modes; The minimum ribbon interval between two lines of printing is not more than 0.5mm |
| Air Pressure Supply | Max. 6 bar/90 psi |
| Airflow Consumption | As low as 4 ml / print at 2.5 bar |
| Print Density Level | Level 31 |
| USB Interface | STD, 1 port, type B connector, USB device 2.0 |
| USB HOST | STD, 1USB disk connection port ; USB Host 2.0, automatic detection and setting of connections |
| Serial Port | STD 1 port, female D-SUB 9-pin connectorDefault 9600, 8/N/1, variable baud rate and format |
| Ethernet Interface | STD 1 port, RJ-45 connector, IEEE802.3 10/100BASE-T |
| Hardware Interface Port | Input: "Print Start" and a configurable input ; Outputs: fault, warning and 2 configurable outputs |
| Power Supply | Internal switching power supply module, I / P: AC90V-264V, 47/63 Hz; 150 VA |
| Software | HPRT Format Designer |
| Certification | CCC |
| Environmental Conditions | Operation: 0 to 40 ° C @ humidity 10% to 90% non-condensing Storage: -40 to 60 ° C @ humidity 10% to 90% non-condensing |
| Machine Dimension | Printer: height less than 190 mm, width less than 220 mm, depth less than 236 mm Controller: height less than 170 mm, width less than 263 mm, depth less than 190 mm |
| Machine Weight | Printer: less than 8 kg ;Controller: less than 5 kg |
| Warranty | Printer: 3 years ; Controller: 3 years ; Thermal head: 6 months or 50 KM;Platen: 5 years |
