High Pressure Water Jet Beveling & Cutting Machine (BPWBM~24A) - 2

Product Description

Performance features
On-line Performance: Very good ( Designed as per the one line equipment of the production line)
Beveling Capacity: ≤ 4Min /pipe bevel (DN200 SCH40)
Bevel cutting: Cutting off pipe & with bevel simultaneously.
Bevel quality: Good
Technical parameters
Pipe diameter applicable: DN100~600(φ 114~610)
Applicable wall thickness: 1~18 mm
Materials applicable: Carbon steel, alloy steel, stainless steel, cryogenic steel and other materials
Cutting length: 6350MM
Bevel Shape: V
Cutting direction: Lengthwise
Roller bench:
Structure: Three line roller with fixed distance
Roller bed Length: 7000MM
Driving System: Servo motor + precision reducer
Rev: 0~2.5M/Min (VF stepless speed adjustment)
Material of the roller bench: Carbon steel packing with rubber
Rotation Accuracy: <2.0MM
Trolley System:
Trolley travel: 6350MM(moving lengthwise)
Cutting torch travel: 700MM (up/down); 300MM (left/right)
Cutting with: High pressure water jet cutting
Water cutting angle: ± 45° (adjustable)
Water cutter quantity: One piece of water jet tool
Angle error: <2°
Length fixing accuracy: <2.0MM
Control System: High CNC Cutting System
Length-measuring system: CNC length measuring which is included in the control system.
Conveying system: Built in a conveying system equipped with a lifter; One set of conveying system can be provided additionally for bevel cutting machine if necessary and conveying can be implemented manually or electrically.
High pressure generator: Our OEM products which are famous in China (or as per customers' demands)
Pressure is increased by: Liquid (by hydraulic system and feeding water)
Oil pump capacity: 90L/Min max
Nozzle diameter: 0.3mm max
Highest pressure: 380MPa
Continuous water pressure: 330MPa
Motor power: 37KW.

---
