High Quality Facial Tissue Paper Interfold Embossing Machine

Product Description

High Quality Facial Tissue Paper Interfold Embossing Machine
Box of Kleenex machine is to cut paper plate processing each transaction is folded into a box of Kleenex, after a pumping tissue machine, use a withdrawn from the box.

Product features:
1.JX-2L/3L/4L type box and effective tissue machine width can reach 560mm-820mm, while the production of 2/3/4 standard soft pumping, which greatly greatly improves the machine output.
2.This machine adopts vacuum adsorption, automatic counting, has the advantages of high speed, accurate quantity, advanced production equipment box of kleenex.
3.The equipment is equipped with the expansion force adjustment device three, in order to guarantee the folding finished product size precision.
4.Machine with pressure side lines and pressure all two kinds of flower embossed function, can meet the production needs of customers.

Technical parameter:

Model	JX-2L/3L/4L
Product Size	200×200±2mm (Other size is available)
Paper Diameter	Φ1300mm (Other size is available)
Paper Core Inner Dia	76.2mm(Other size is available)
Speed	0-180m/min
Controller	Electromagnetic speed
Embossing Device	Steel to steel embossing
Embossing Roller End	Felt roller, wool roller, rubber roller, steel roller
Blank Lines	Steel on steel, the independent regulator
Cutting system	Pneumatic point cut
Vacuum System	7.5kw
Pneumatic System	3 air compressor, at least the pressure 5kg/cm2 Pa
Host Power	3 kw
Dimension	5150mm×1300mm×1920mm
Weight	Dependind on the model and configuration to the actual weight
Optional
Use of power	Frequency Control, Electromagnetic speed
Embossing Device	Steel to rubber roller, steel to steel embossing, steel to felt roller, wool roller of steel
Embossing Roller End	Felt roller, wool roller, rubber roller, steel roller

Finished product

Company Information
Zhengzhou Dingchen Machinery Co., Ltd., located in Central China, is a professional machinery manufacturer focusing on the R&D and production of paper making machines.Our products include paper making machines,pulp making machine,parts and paper converting machines such as kraft paper machines,corrugated paper machines,tissue/toilet paper machines,office paper machines, newspaper machines and so on. Our factory gathers and trains many essential technicians and management system to ensure all products meet the quality of ISO and update constantly!
Our products have been exported to many countries and regions, such as America, Egypt, India, Fiji, Iran, Ghana ,Paraguay, Russia, Syria,Pakistan, Tanzania, and Uzbekistan. Our products and services have won customers' consistent affirmations.have won customers' consistent affirmations.We have a large scale of products regarding paper machinery, including:A.Pulping equipment (D-type hydrapulper, cleaner, DD refiner, pressurescreen, screen basket, pulp pump etc.)B.Paper machinery (Tissue/Toilet paper machine, Multi-fourdrinier papermachine, head box, cylinder mould, dryer cylinder, roller etc.)C.Paper making finished devices (Paper calender, pope reel,size press,paper rewinder etc.)Meet customers' requirements and exceed customers' expects.We wish to found long-termcooperation with your companyTechnical Advantage1.Experienced producing team2.Advanced technological strengthProduct Advantage1.Through the international authentication2.The same material the most preferential price3.A lot of varieties for the customer to chooseService Advantage1.Technical consultation2.Project evaluation3.Detailed design of factory4.Installing and testing the whole production line5.Training engineers and workers6.Supplying spare parts for long timeThe business process1.send your requirements:raw material,capacity,paper grammage2.we make the solution to you3.come visit and negotiate4.sign contract5.first payment6.production7.pay spare money8.delivery9.installation ,training,test run10.production consultlation
