Heavy Duty Lathe Machine (CW6180B)

Product Description

Heavy Duty Lathe Machine(CW6180B)
Features:
CW6280 parallel lathe are suitable for turning internal and external cylindrical, conical and swing surfaces as well as various metric, inch, module and diametric pitch threads.They can also be used for broaching oil grooves and keyways. There are also following features:
1. Box type internal structure, of high rigidity , with hardened guideway. The precision is stable.And can carry out strong force cutting.
2. On apron,there is a device, operated by a single lever, used for rapid traverse of the carriage.
3. The saddle guideway is glued by 'TSF' soft belt wear resisting materials.
4. The top slide can be used independently for turning of short cone, in combination with longitudinal feeding, it can also turn long taper surface.
Specification:

Model		CW6280B
Max swing over bed	mm	800
Max swing over carriage	mm	520
Center distance	mm	1500,2000,3000 to 12000
Max swing over gap	mm	1000
Spindle bore and type	mm	104 C11
Spindle taper	mm	MT5
Spindle speed and range	R/min	18kinds 6-800
Longitudinal feed	mm/r	64kinds 0.1-24.3
Cross feed	mm/r	0.05-0.76
Rapid moving speed	mm/min	4000
Metric thread	mm	50kinds 1-240
Inch thread	t/in	26kinds 14-1
Module thread	mm	53kinds0.5-120
Diametral pitch thread	DP	24kinds 28-1
Cross slide travel	mm	420
Top rest travel	mm	200
Tail stock sleeve travel	mm	250
Tail stack taper		MT5
Bed width	mm	550RC52
Main motor power	kW	11
Moving motor power	kW	1.1
Coolant motor power	w	125
Machine width and height	mm	1450×1630
1500	mm	3690
2000	mm	4190
3000	mm	5190
4000	mm	6190
5000	mm	7190
Max loading capacity
1500	kg	2500
2000	kg	3000
3000	kg	3500
4000	kg	4000
5000	kg	4500

---
