Selling at a Low Price New Lathe Machine 3 Axis Atuomatic Kgs-820 Ahd Grinding Machine

Product Description

Product Description
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
General Specification
-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Machine Equipment
A full-supported double-V structure design is adopted to the workbench, equipped with Turcite-B and a manual scraper to ensure excellent smooth operation and grinding accuracy under load.
X-axis movement is hydraulic driven.
- The Y axis is driven by AC servo motor and C5 ball screw.
Automatic central lubrication.
- Independent Hydraulic System,Avoid the impact of vibration on the machine.
-The automatic down-feed gearbox is designed to achieve ffne and accurate down-feed increments.
- The flanged cartridge type spindle is supported by P4 super precision angular contact ball bearings.

- Magnetic separator with 200L tank for effective cooling and rinsing. (Optional)
- KENT electro magnetic chuck.
Power supply = DC 110 volt, Single-phases, 50 Hz /60 Hz.
- KENT Y&Z axis digimatic gage.(Optional)

The grinding wheel dresser uses an adjustable hydraulic system at the front and rear, and is driven by a handwheel for the upper and lower wheels.

-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Standard Equipment
Consisting of:

Granding Wheel Flange	Flange Removal Tool	Balance Table
Balance Rod	Grinding Wheel (Φ508*50*Φ127)	Tool Set
Machine to Adjust Sizing Block	Complete Document	Acceptance report According to DIN 8632

(Please note that standard accessories may vary depending on the specific model selected.)
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Product Parameters

Granding Range	mm	2000*800
Cross Travel	mm	885
Longitudinal Travel	mm	2250
Size of Electro-Permanent Chuck	mm	2000*800
Distance Table to Spindle Center	mm	850
Table Lode incl. Magnetic Chuck	kg	2300
Longitudinal Table Speed	m/min	10~28
Infeed Cross Axis (50Hz / 60Hz)	mm/min	1500/1500
Infeed Vertical Axis (50Hz / 60Hz)	mm/min	240/300
Grinding Wheel Dimensions	mm	Φ508*50*Φ127
Grinding Spindle Drive	hp(kW)	15(11.25)
Variable Speed of Grinding Spindle Motor	rpm	1000/1200
Machine Weight	kg	15500
Floor Space	mm	6000*3360

-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Company Profile
Transtar Machinery Co., Ltd. is located in Dongguan, known as the "Factory of the World". We are a company specializing in the production and sales of machine tools and tools, with products ranging from traditional machine tools and tools to CNC machine tools everything, tailored to the needs of customers. The company has a specialized R & D team, from castings to the body, from the circuit to the system layers of control, so that the company's products are constantly updated, constantly improved, and to date we have nearly thirty years of experience in the industry, can provide customers with the industry's more cutting-edge quality products. Our main types of business include, but are not limited to, surface grinders, CNC grinders, lathes, machining centers, 5-axis machines, mill-turn machines, gantry machines, and related ancillary products. We have a wide range of machine tools with competitive prices and great influence in the industry. We develop global customers with high quality products and the best service, and since the establishment of our company, we have been adhering to the business philosophy of "Professional Quality, Reputation First, and Customers First", and we are constantly pursuing excellence to create greater value for our customers. We are committed to becoming the industry leader and contributing to the development of machinery manufacturing, for which we have been working hard to serve every one of our customers and are committed to realizing the development goal of becoming an important member of the global market, and working hand in hand with our customers to create a better future!
FAQ
Q1:Can we visit your factory before order?A: Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick you up at the station or airport if needed .
Q2:What's your main products of your company?A: We specialized in all kinds of machine tools,such as CNC Lathe Machine, Turning and Milling Compound Lathe Spindle Cnc Lathe Machine,Lathe Feeder Machine and so on.Q3:Can you provide customized machines?A: Yes, we can design and manufacture according to your specific requirements.Q4:Do you have professional engineers?A: Yes,we have professional engineers and designers.Q5: Does your company provide professional training?A: Yes, we provide training and teaching or use video teaching.Q6:How can I choose the most suitable machines?A: You can contact our customer service, and please provide your product details and requirements, then we will help you choose the most suitable machine based on your information.Q7:What is your terms of delivery?A: FOBQ8:What is your terms of payment.A:TIT 30% as deposit, and 70% before delivery.We'll show you the photos of the products and packages before you pay the balance.Q9:How about your delivery time?A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.Q10: Do you test all your goods before delivery?A: Yes, we have 100% test before delivery.Q11:Can you provide product samples?A: Yes, we can provide samples according to the drawings, but the customer needs to pay for the cost of the samples.Q12:What industry are your machines used in?A:Automobile parts industry,Electronic Equipment Industry, Home appliance industry, and so on.

---
