Welcome to visit

Plastic Cap Compression Molding Machine

US$80,000.00 1 SET (MOQ)

Basic Info.

Model NO.
LTY-YG-M
Type
Cap Compression Molding Machine
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Plunger Type
Clamping Way
Hydraulic
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008, GMP, QS
Transport Package
Wrapping Film Packing/Wooden Case
Specification
16 cavities
Trademark
LOYALTY
Origin
China
Production Capacity
100sets/Month

Product Description

Maintance:
1. The suitable temperature is 25-28 degree. It is good to install thermometer in your workshop.
2. The machine can run 24 hours. For maintance, please stop the machine after half month.
3. Please add mould oil on the mould every half month.
4. Please clear and put anti-rust agent on the mould which is taked out from the machine.
4. Please use good water for chiller, and put anti-rust powder sodium nitrite in the water.
5. It needs 200 liters oil for hydraulic oil pump. Please filter the oil every year.
6. It is good that there is one factory manager for machines.

After Sale Service:
1. Upon arrival of the machines at your factory, we will send an engineer to install and test all machines
until qualified caps are produced. Engineer service is free in one week and you should finish the
installation, maintenance and training in one week. If overtake one week, you should pay US$100
per day to the us for every calendar day until all things are finished. You shall be liable for all the
expenses of air-tickets, food and housing of the Seller's engineer, and a qualified translator shall be
made to the Seller's engineer during the trip.
2. We shall train your qualified personnel to the operation, service and maintenance procedures of all
machines and equipments.

Image Item No. & Description
16-Cavity Cap Molding Machine LTY-40B-16 1.The Main Cap Diameter: 26-38mm 2.Productivity:8000-10000pcs/hour for 28mm cap, 11000-13000pcs/hour for 30mm cap 3.Installed Electrical Power: 30 KW (50Hz) 4.Consumed Electrical Power: 21 KW 5.Size: 3700(L)X1500(W)X2200(H) 6.Weight: 4000kg 7.Chiller needed: 10HP
