PE Film Shredder/PP Film Shredder/ Woven Bag Shredder

Product Description

3E MACHINERY's SWTF series Film Shredder adopt double film shafts design that rotate a medium speed, low noise and high efficient without pusher. Adopt SIENMENS LOGO microcomputer control system with function of start, stop, automatic reverse sensors to protect the machine against over loading and jamming.
It is especially suitable for recycling the medium hardness and soft material, for example film, woven bag, jumbo bag, paper and ect. Aiming at different material, it could use different shaft.
Application
SWTF3080 series is our conventional range of small size film shredders. Suitable for recycling the medium hardness and soft material, for example film, woven bag, jumbo bag, paper and ect. Aiming at different material, it could use different shaft.
Specification
SWTF3080 series is our conventional range of middle size film shredders. Controlled by microcomputer (PC), featuring start, stop, reverse functions. It is fitted with an automatic overload return mechanism to prevent damage to rotor and other parts. And It has advantage of high efficiency, low noise and economical etc.

Item Model	SWTF3080
Dimension L/W/H(mm)	1834×1561×1735
Cutting Chamber C/D(mm)	800×576
Height of discharge port E(mm)	535
Rotor Diameter (mm)	φ313
Main Shaft Speed (r/min)	82
Screen Mesh (mm)	Z40 (Z Style)
Rotor-knives (pcs)	(26×2)+(28×2)
Stator-knives (pcs)	4
Main Motor Power (kw)	30+30

Features
Certification
3E MACHINERY was awarded 18utility model patents and 3 invention patents.
Company profile
3E GROUP is an integrated company specialized in developing, manufacturing, distributing and providing recycling machinery solutions. Our main entity " Guangzhou 3E Machinery CO. Ltd" founded in 2003, has currently become focusing on "Shredding" and "Recycling industry" modern enterprise. Technology is the core-competitiveness of 3E Group, we are active in the recycling market and keep cooperating with well-known enterprises in Europe and the USA. Meanwhile, 3E Group keeps on improving and innovating, so far, we awarded 18utility model patents and 3 invention patents. "Efficient Economical & Environmental" is the traditional idea of 3E Group. With its own intellectual property and solid technological team, our products have been already sold to over 90 regions and countries which include the USA, Europe, Australia, Southeast Asia, Latin America, and Middle East.
Our service 1.Pre-sale support
3E Machinery consists of experienced specialists, we will offer a suitable solution according client's requirement in time.
On-site inspection.
2. After-sale service
3E's skilled technicians are available to assist with onsite installation, commissioning & training on request. This will enable customers to optimize the performance of their new plant. Customers will be briefed on all aspects relating to operation and maintenance by a 3E technician. Dimensional drawings together with service requirements will be provided prior to delivery of the equipment. This will allow the customer to prepare the site and allow them to commence production in a timely fashion.
3E holds a adequately inventory of spare parts and their efficient service personnel will ensure that any required part will be dispatched without delay. Delivery of the spare parts may be by air, sea or courier depending on the urgency of the situation. Customers are encouraged to hold their own critical spare parts such as granulator blades and screens to ensure optimal machine condition and performance.
3. Technical support
3E provides enough hardware resource especially for large-scale production lines, clients can carry out installation, commissioning and acceptance before delivery.
Regular return visit.

---
