Wojie Wj650ds Gang Type CNC Double Spindle Turning Center Siemens Fanuk GSK System Automatic Slant Bed CNC Lathe Machine for Metal

Product Description

Product Description
This series of machine tools adopts an integral bed with a 30° bevel angle, and the bed material is HT300. It is cast using resin sand technology and has a reasonable internal rib layout. The guide rail adopts imported linear roller guide rail, which has improved feeding accuracy, small friction resistance, good rigidity, high resistance to vibration and deformation, allowing users to obtain higher processing accuracy, increase the speed of rapid movement, and obtain higher production efficiency.
Product Parameters

Machine type	WJ650DS-500/750	WJ650DS-500/750
Maximum upper rotating diameter of bed	Φ650	Φ650
Maximum machining diameter	Φ250(BMT45Y)	Φ370(BMT55Y)
Maximum machining diameter on tool rest	Φ250	Φ370
Maximum machining length	420/650 BMT45Y	420/650 BMT55Y
Spindle head type	A2-6 (8" chuck)	A2-6 (8" chuck)
Recommended spindle motor power	11-15KW	11-15KW
Spindle maximum speed	3500rpm	3500rpm
Spindle hole diameter	Φ66	Φ66
Bar diameter	Φ52	Φ52
Sub-spindle head type	A2-5 (6″ chuck) electric spindle	A2-5 (6″ chuck) electric spindle
Spindle maximum speed	5000rpm	5000rpm
Spindle hole diameter	Φ56	Φ56
Bar diameter	Φ42	Φ42
X/Z axis screw specification	3210/4010/3210	3210/4010/3210
X/Z axis limit travel	260/610-270/810	260/610-260/810
X/Z axis rail specification	45/45	45/45
Sub-axis rail specification	35	35
Sub-axis limit travel	350/650	350/650
Optional turret (special configuration)	BMT55Y (power turret)	BMT55Y (power turret)
Y axis travel	±45	±45
Bed type and slope	Integral/30°	Integral/30°
Overall dimensions (L*W*H)	3300/3600*2130*2320mm	3300/3600*2130*2320mm
Overall dimensions (L*W*H) with chip conveyor	4045/4345*2170*2490mm	3300/3600*2130*2320mm
Weight (approximate weight)	4500kg/5400kg	4600kg/5500kg
Approximate weight (with chip conveyor)	4800kg/5700kg	4900kg/5800kg

Detailed Photos

Control system Standard configuration: GSK Optional configuration: Siemens/ Fanuc/ Syntec/ Mitsubisin	Turret For CNC Lathe Machine, standard is hydraulic turret For CNC Turning Center,standard is power Turret
Hydraulic chuck Standard configuration:8"	Sub-spindle Standard configuration:6"
3-axis linear guide Using high-precision Taiwanese or Japanese brands, HIWIN/PMI/THK, etc.	Lead screw 3-axis lead screw, using high-precision Taiwanese or Japanese brands, HIWIN/PMI/THK, etc.
	Pneumatic system With electronic display, better stability, when changing tools on the equipment and spindle, the air pressure will be very stable and there will be no tool jamming
Lubrication system The centralized lubrication system can be used in a timely, quantitative, accurate, efficient, convenient and reliable manner, and is conductive to increasing the service life of the machine tool.	Electrical part Standard configuration: DELIX

Optional Accessories
Company Profile
ZAOZHUANG WOJIE CNC MACHINERY Co., LTD. has:
More than 60,000m² of the factory with more than 150 workers. Strictly QC control with more than 24 steps testing processes 30+ years CNC machine manufacture experience factory 24 hours online service at any time Trade with customers in more than 150 countries around the word. Cooperate with the Famous Brand, such as SIEMENS, FANUC, SYNTEC ect. Support ODM OEM. Warranty time is 24 months Certifications
FAQ
1. What are the payment terms?
A: T/T, 30% down payment when ordering, 70% balance before shipment; irrevocable L/C at sight.
After receiving the advance payment, we will start production. After the machine is ready, we will take pictures and videos for you to inspect the machine. After paying the balance, we will send the machine to the designated location according to your instructions.
2. What does your company mainly produce?
A: Our company is a professional machine tool manufacturer with many years of experience. The company mainly produces CNC milling machines, CNC lathes for machining centers, ordinary milling machines, ordinary lathes, hydraulic presses, etc.
3. When is the delivery time?
A: If the machine you ordered is a standard machine, we can prepare the machine within 15 days. If it is some special machines, the delivery time is about 30 days. Some machine models will be in stock, please consult the salesperson for details.
4. What are your trade terms?
A: FOB, CFR, CIF, DDP, DAP, FCA, etc.
5. What is your minimum order quantity and warranty period?
A: The minimum order quantity is 1 set, and the warranty period is 2 years. But we will provide lifetime service for the machine.
6. What is the packaging of the machine?
A: The machine is placed on a metal pallet, covered with a moisture-proof coat inside, and wrapped with plywood all around.

---
