Ball Race Bearing Ball Bearing Truck Trailer Turntable

Product Description

Ball race bearing Ball bearing truck trailer turntable
Ball race bearing Ball bearing truck trailer turntable
1>Semi-trailer and heavy truck turntables.
2>Double track and single track are available.
3>Mechanical turntable is available.
4>Different outside diameter is available.
5>Different inside diameter is available.
6>Different height is available.
7>Different thickness of the material is available.
8>Surface treatment is according to customers' demand.

Ball race bearing Ball bearing truck trailer turntableTechnical Parameters:

U Type Single Ball/Casting turntable:

Item No.	A	B	E	F	H	Weight	Ring Thickness	Ball Dia.
	mm	mm	mm	mm	mm	Kg	mm
LHTS500-A01	500	500	392	376	55	32	10	16
LHTS685-A01	685	700	590	565	80	45	13	16
LHTS880-A01	880	895	779	754	80	60	13	16
LHTS1000-A01	1000	1015	885	860	80	76	14	22
LHTS1000-A02	1022	1013	879	856	90	85	14	22
LHTS1000-A03	1000	1015	885	860	90	84	14	22
LHTS1100-A01	1100	1115	985	960	90	98	15	22
LHTS1100-A02	1100	1111	983	949	90	98	15	22
LHTS1200-A01	1200	1211	1083	1050	90	110	15	22
LHTS1300-A01	1300	1315	1180	1146	90	118	16	22
LHTS1300-A02	1300	1315	1185	1160	90	118	16	22

U Type Double Ball/Casting turntable:

Item No.	A	B	E	F	H	Weight	Ring Thickness	Ball Dia.
	mm	mm	mm	mm	mm	Kg	mm
LHTD650-B01	650	665	552	510	80	74	14	16/19
LHTD880-B01	880	895	780	740	80	80	14	16/19
LHTD1000-B01	988	1000	870	830	92	88	14	16/19
LHTD1096-B01	1096	1110	990	950	80	100	14	16/22
LHTD1100-B01	1095	1108	975	940	92	100	15	16/22
LHTD1200-B01	1195	1208	1076	1040	92	118	15	16/22
LHTD1200-B02	1198	1215	1075	1040	92	120	16	16/22

Z Type Single ball/casting turntable :

Item No.	A	B	E	F	H	Weight	Ring Thickness	Ball Dia.
	mm	mm	mm	mm	mm	Kg	mm
LHTS500-D01	500	437	379	310	52	25	10	16
LHTS650-D01	650	587	523	465	52	32	10	16
LHTS750-D01	750	687	620	565	52	36	10	16
LHTS850-D01	850	787	723	665	52	41	10	16
LHTS950-D01	950	888	820	752	56	45	12	16
LHTS950-D02	952	885	821	750	60	48	12	20
LHTS1050-D01	1050	987	923	865	52	53	12	16
LHTS1100-D01	1102	1027	923	854	56	61	12	20

1. Q:What's your best price for this product?
A: We will quote you best price according to your quantity, so when you making an inquiry, please let us know the quantity you want.The more quantity the better price.
2. Q:How about the quality of this product?
A: Our products are certified to ISO9001, international quality standards. We company have very strict Quality Control Systems.
3. Q:What's your MOQ?
A: 1pc for each model. We hope you can buy more to save more money.
4. Q:What's the delivery time?
A: For products that are in stock, we can ship it within 7 days after receiving your payment. For custom order, quantity within 24 tons, production time is 20-25 days after every details confirmed.
5. Q:What's your packing?
A:Our usual packing is pallet, we can also supply your packing according to your requirements.
6. Q:Can we custom our own logo or label on this product?
A: Yes, you can. we support logo print & stamping & label print, print will be free if the logo is not very complex.
7. Q:What about the warranty?
A: We are very confident in our products, and we pack them very well to make sure the goods in well protection.
8. Q:What is the Payment Terms?
A: T/T,L/C,Western Union,Moneygram,Paypal.
9. Q:What is the shipment way?
A: By sea,by air or by express,it depends on how much of goods,by sea is the most economical way.
10.Q:Can you send me price as soon as possible?It is urgently!
A: In order to get the price fastly and accurately,it will be appreciated if you could provide the technical drawing or OE No.,for custom goods,the actual goods sample will be better.

---
