1/8 Inch Titanium Rod Ta5 DIN Tial4b Ta2 DIN Titanium Price Per Kg of Surgical Implant Titanium Bar

Product Description

Product Description titanium round bars and rods
Round bar is made from very small diameters of wire for welding, all the way up to larger diameters (such as the 14″ diameter), used for clutch and flywheels.The medical field often uses small-diameter round bar for body implantable fasteners and dental appliances.
Standard: ASTM B/SB 348; ASTM B/SB 381,ASTM F136; ASTM F67, AMS4928, ISO5832-2/-3,
Available grades : Gr1, Gr2, Gr3, GR4, Gr5, Gr7, Gr9, Gr12....GR36
Available sizes:
Diameter : 0.1mm up to -350mm
Length: 20-6000mm for rods and bars, 0.1kgs-100kgs /coll for wires
Titanium square bars and rods
Titanium square bars have the square side. The most popular grade is GR2, GR3, GR4, GR5.
Available sizes:
a: 4mm up to 450mm
b: 50mm up to 6000mm
Popular sizes: a*a*b 6*6*b 8mm*8mm*b 10mm*10mm*b 12mm*12mm*b 16mm*16mm*b

SPECIFICATIONS FOR TITANIUM ROUND BAR
Product Name	Titanium Bar
Standard	AISI,ASTM, EN, BS, GB, DIN, JIS
Diameter	3mm-500mm
Dia Tolerance	H9 / H11 / H13 ,or requirement
Materials	TC4/Ti-6Al-4V Ta2 ta1 TA4 TA7/Ti-5Al-2.5Sn TA10 TA9 TC1 TC11 TA5 TA0 TC6 TA6 TA15 TC9 TC12 TA18 TA3 TC10 Tc3 tc8 TC20 TB2 TA20 TC7 TB8 TA19 tb3 TA14 TC5 Tc2 TC18 TC17 tb5 TA8 TC16 TA12 TA17 TA5E tb4 ta16 bt15 TA11 ZTC4 TB6 TA15-1 TC15 BT3-1 TA21 tc19 BT1-0 bt6c TB7 BT9 BT8 BT6 TA13 IMI315/Ti-6Al-6V-2Sn IMI230 Ti-15-3-3-3
Surface	Polished bright,black,Grinding
Inspection	ISO,BV,SGS,MTC
Packing	Waterproof paper, and steel strip packed. Standard Export Seaworthy Package.Suit forall kinds of transport,or as required
Supply Ability	1000 metric tons/month
MOQ	500kgs
Shipment time	Within 7-10 workdays after receiving deposit
Payments	T/T

Chemical Composition (%)

Grade	N(≤)	C(≤)	H(≤)	Fe(≤)	O(≤)	Al(≤)	V(≤)	Pd(≤)	Mo(≤)	Ni(≤)	Ti
GR1	0.03	0.08	0.015	0.2	0.18	/	/	/	/	/	bal
GR2	0.03	0.08	0.015	0.3	0.25	/	/	/	/	/	bal
GR3	0.05	0.08	0.015	0.3	0.35	/	/	/	/	/	bal
GR4	0.05	0.08	0.015	0.2	0.4	/	/	/	/	/	bal
GR5	0.05	0.08	0.015	0.4	0.2	5.5~6.75	3.5~4.5	/	/	/	bal
GR7	0.03	0.08	0.015	0.3	0.25	/	/	0.12~0.25	/	/	bal
GR9	0.03	0.08	0.015	0.25	0.15	2.5~3.5	2.0~3.0	/	/	/	bal
GR12	0.03	0.08	0.015	0.3	0.25	/	/	/	0.2~0.4	0.6~0.9	bal
GR23	0.05	0.08	0.012	0.25	0.13	5.5~6.5	3.5~4.5				bal

Mechanical property

Grade	Tensil strength(≥)		Yeild strength(≥))		Elongation(≥)%)
	ksi	Mpa	ksi	Mpa
GR1	35	240	20	138	24
GR2	50	345	40	275	20
GR3	65	450	55	380	18
GR4	80	550	70	483	15
GR5	130	895	120	828	10
GR7	50	345	40	275	20
GR9	90	620	70	483	15
GR12	70	483	20	345	18
GR23	120	828	110	760	10

Product characteristics Titanium is a chemical element with the symbol Ti and atomic number 22. It is a lustrous transition metal with a silver color, low density, and high strength. Titanium is resistant to corrosion in sea water, aqua regia, and chlorine.

Alloy	Specifications	UTS (psi)	YS (psi)	EI (%)	RA (%)
		ksi min.	ksi min.	% min.	% min.
CP-1	ASTM B265 / B348 Grade 1	35	20	24	30
CP-2	ASTM B265 / B348 Grade 2	50	40	20	30
CP-3	ASTM B265 / B348 Grade 3	65	55	18	30
CP-4	ASTM B265 / B348 Grade 4	80	70	15	25
Ti 6AI-4V	ASTM B265 / B348 Grade 5	130	120	10	25
Ti 6AI-4v ELI	ASTM B265 / B348 Grade 23	120	110	10	15
Ti-Pd	ASTM B265 / B348 Grade 7	50	40	20	30
TiCode 12	ASTM B265 / B348 Grade 12	70	50	18	25

product application Aerospace Applications
Due to their high tensile strength to density ratio, high corrosion resistance, and ability to withstand moderately high temperatures without creeping, titanium alloys are used in aircraft, armor plating, naval ships, spacecraft, and missiles.
Industrial Applications
Titanium is used in engine applications such as rotors, compressor blades, hydraulic system components and nacelles. Titanium 6AL-4V alloy accounts for almost 50% of all alloys used in aircraft applications.
Consumer and Architectural Applications
Titanium metal is used in automotive applications, particularly in automobile or motorcycle racing, where weight reduction is critical while maintaining high strength and rigidity.
Medical Applications
Titanium has the inherent property to osseointegrate, enabling use in dental implants that can remain in place for over 30 years.
FAQ 1.Are you a manufacturer or a trader?
We're a manufacturer with more than years of professional production experience.
2.Can you accept OEM?
Yes, OEM is acceptable. Just pls provide us with the drawing or sample, we will production totally according to your requirements.
3.Can you provide us with the design drawing?
Yeah, of course, we will provide you with the drawing after you paid or prepaid.
4.Can your factory produce products according to our drawings?
Yes, we can. Most products can be customized, including the Logo on products.
5.What kind of your packaging?
Neutral plywood or wooden box packaging or according to customer's requirements.
6.How long is your delivery time?Which ports are accepted for delivery?
Normally 30days after payment, and we promise we will deliver as soon as we can.It can be delivered from Qingdao, Tianjin, Shanghai, Guangzhou and other ports.
7.How can we get your price ?
A. We need below information to quote for you:
1). Product Name
2). Standard
3). Material Grade (Chemical Composition)
4). Dimension
5). Quantity

---
