Rul Material Refractoriness Under Load Tester ISO1893

Product Description

Product Description
CHY-II-17 Material refractoriness under load tester
The instrument can be used for refractories, ceramics, graphite materials, such as high temperature refractoriness under load (RUL) test, refractoriness under load represents the material resistance to high temperature and load at the same time, but also represents the material to show obvious plastic deformation of the softening temperature range.
The equipment is manufactured in accordance with the requirements of YB/T 370 "experimental method of refractoriness under load for refractory products (non-differential - temperature rise method)". At the same time also meet GB/T5989-2008 and ISO1893:2007 < Refractory products- Determination of refractoriness under load -differential method with rising temperature>, there are a variety of structures to meet the different materials of the refractoriness under load test purposes. Using Windows operating interface, the experiment process to achieve automatic data acquisition and control, automatic generation of test curve, automatic analysis, and print the experiment report by chart data output.
Product Parameters
The main technical parameters:
1. Heating temperature: up to 1700ºC; Use temperature: 1600ºC,
temperature control accuracy: heating section up to: less than ±2ºC.
2. Heating rate: 0-20ºC/ min; Arbitrary setting
3. Heating mode: manual or automatic program heating; More than 30 stages of program heating.
*4. Can pass protective gas, inert gas, static, dynamic.
5. Deformation measurement range (mm) : 0 ~ 10, error: <= 0.03mm;
6. Sample size: high 50±0.5mm; Diameter 36±0.15mm;
Or high 50±0.5mm; Diameter 50±0.35mm;
7. Uniform temperate zone height is ≥75mm; Temperature difference <=20ºC;
8. Maximum power: 6KW;
9. Sample load pressure: 0.2Mpa;
10. The pressure mode can be direct pressure digital display,
Loading range (N): 100 ~ 1000, accurate to 1N.
11. Using open-type furnace makes replacement of upper & lower pressure bar is very convenient and the independent loading system enables high accurate loading precision.
12. It can be connected with computer to realize automatic control, English operation interface, automatic printing of test report.
13: The electric control adopts intelligent regulation, with over-current and over-temperature decoupling alarm function.
Complete list of products:

Items	Name	Model/Size	Unit	Qty	Marks
Host machine	Material refractoriness under load tester	CHY-II-17	set	1
Random files	User manual of Material refractoiness under load tester		pc	1
	Instruction manual of the intelligent digital meter		pc	1
	Heating elements		pc	6	2pcs for spare
	Testing software	English	pc	1
Accessories	Weights	2KG	pc	10	customized
	Balance		pc	2
	Rubber tube	Diameter 8 mm	pc	1
	Up,lower pressure bar	Up:Ф40×220(mm) Lower:Ф40×195(mm)	pc	Each 1
	Up,lower gasket	Ф50×10(mm)	pc	Each 1
	*Computer		set	1	User prepare
