Ultrafine Powder Grinding Spiral Disc Jet Mill for Pharmaceutical

Product Description

Product Description Spiral jet mill is a horizontal oriented jet mill with tangential grinding nozzles located around the peripheral wall of the grinding chamber. Materials are speeded up through venturi nozzle by a high-speed fluid discharged by pusher nozzle and enter into a milling zone. In the milling zone materials are crashed and milled each other by the high-speed fluid discharged from grinding nozzle. Grinding and static classification both occur with a single, cylindrical chamber.
Capable of grinding dry powders to 2~45 micron averages. After centrifugal force classify powders, fine powders are discharged from outlet and coarse powders are repeatedly milled in the milling zone.
Material of the inner liner can be selected from Al2O3, ZrO2, Si3N4, SiC etc. Simple inner structure makes disassemble, cleaning and washing easy.
Features • Laboratory up to Production Models
• Improved Grinding Efficiency
• Low noise (less than 80 dB)
• Replaceable grinding nozzles and liners
• Sanitary designs for access to gas and product contact areas
• Simple design ensures rapid disassembly for easy cleaning and Changeover
• Specialized liners for abrasive or sticky materials
Applications • Pharmaceutical
• Aerospace
• Cosmetic
• Pigment
• Chemical
• Food Processing
• Nutraceutical
• Plastic
• Paint
• Ceramic
• Electronics
• Power Generation
Product Parameters

Model	Air Consumption (m3/min)	Working Pressure (Mpa)	Target Size (micron)	Capacity (kg/h)	Installed Power (kw)
DCS-50	0.5	0.6-0.8	2-45	0.005-0.5	8
DCS-100	1	0.6-0.8	2-45	0.5-5	10
DCS-150	2	0.6-0.8	2-45	5-20	15
DCS-300	6	0.6-0.8	2-45	10-150	45
DCS-350	10	0.6-0.8	2-45	50-300	75
DCS-600	20	0.6-0.8	2-45	100-500	160
