Industrial V Powder Blender Mixer for Pharmaceutical Nutriceutical Chemical

Product Description

Product Description The structure of this machine is unique. Its mixing efficiency is high and no dead corner. It is made of stainless steel . its inner and outer wall is processed through polishing. Its apperance is beauty.
Its mixing is uniform. Its scope of application is wide. The forced stirrer can also be equipped in order to meet the requirements of raw materials that contain fine powder, cake and certain moisture as request.
Features One end of the machine is equipped with a motor and a reducer, and the motor power is transmitted to the reducer through the belt, and the reducer is then transmitted to the V-barrel through the coupling. The V-shaped barrel is continuously operated, and the materials in the barrel are driven to mix up, down, left and right in the barrel.
Applications It is suitable for the mixing of powder and granules with good material fluidity and small difference in physical properties, as well as the mixing of materials with low mixing degree requirements and short mixing time, because the material flow in the V-type mixing container is stable and will not destroy the original shape of the material, so the V-type mixer is also suitable for the mixing of fragile and easily worn granular materials, or the mixing of finer powder, lumps and materials containing a certain amount of water, which is widely used in pharmaceutical, chemical, food and other industries.
Product Parameters

Model	V-0.18	V-0.3	V-0.5	V-1.0	V-1.5	V-2.0	V-2.5	V-3.0
Capacity (kg/batch)	72	90	150	300	450	600	800	900
Mixing time (min)	4-8	6-10	6-10	6-10	6-10	6-10	6-10	8-12
Volume (m³)	0.18	0.3	0.5	1.0	1.5	2.0	2.5	3.0
Stirring speed (rpm)	12	12	12	12	12	12	12	10
Power of motor (kw)	1.1	1.1	1.5	3	4	5.5	7.5	7.5
Weight (kg)	280	320	550	950	1020	1600	2040	2300

Related Products
High Speed Mixer Trough Type Mixer Nauta Mixer
Company Profile
Changzhou General Equipment Technology Co., Ltd. is located in LiYang city, a famous scenic and tourist city in JiangSu Province. It is a high-tech equipment manufacturing enterprise . The company is located in the local High-tech Machinery Industrial Park, with very convenient transportation.

The company covers an area of 70,000 square meters, plant area of 50,000 square meters, nearly 100 employees. The company has high-end processing equipment & testing equipment; It has D1 and D2 pressure vessel design qualifications and A2 pressure vessel manufacturing qualifications.Our main products are including Jet Mill Micronizer, Mixer, Granulator and Dryer, Chemical Equipment: Reactor, Heat Exchanger, Column, Tank and Environmental Protection Equipment, etc .
We provide technology research and development, process design, equipment manufacturing, installation and commissioning, project contracting and other comprehensive services. Our products are quite widely applied in the industry of petrochemical industry, Pharmaceutical , Agricultural Chemistry, New Energy, thermal power, steel smelting, Environmental Protection and other Service.Our customers are from the domestic and overseas markets, product quality and fantastic service are deeply praised by customers and partners.
We adhere to the concept of "Scientific Management, Advanced Technology, Quality Priority & Win-Win Cooperation", pursue the enterprise purpose of "Market by Quality, Win customers by Reputation, and seek development by Science & Technology", carry forward the enterprise culture, deepen the enterprise management, enhance the enterprise image, actively create new high-quality products, to provide customers with the superior quality.
Sincerely welcome all customers to visit our company for guidance and cooperation, let's make a better future together.
