75mmx20d Exhaust-Type Cold Feed Rubber Extruder High Quality/CE Certified

US$30,000.00-38,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
75
Condition
New
Customized
Customized
Automatic Grade
Automatic
Structure
Horizontal
Type
Rubber Extruder
Model Number
Bne90-01-00
Screw Diameter
90mm
Color
Based on Customer Demand
Dimension(L*W*H)
3200*1200*1620mm
Weight
3500kgs
Power
75kw
L/D
20:1
Vacuum System
Yes
Screw Speed
2-55
Gear Reducer
18.5:1
Capacity
320kg/Hour
Place of Origin
Zhejiang, China (Mainland)
Transport Package
Wooden Pallet
Specification
90mm
Trademark
BAINA
Origin
Zhejiang
HS Code
8477209000
Production Capacity
10 Set/Sets Per Month

Product Description

we are specilize in rubber extrusion machine and vulcanization machine for rubber sealing profile , rubber hose, silicon rubber profile, butyle rubber tape and sheet product, insulation rubber sheet and pipe products More information please contact us freely.
Salis zhou
Various types of basic parameters:
Item Diameter of screw(mm) L/D ratio speed of screw(r/min) Driving power(kw) Max output of production (kg/h) Weight(kg)
150mm 20D (vacuum) 150 20:1 0-45 160 1000 6500
150mm 16D 150 16:1 0-45 132 800 6500
120mm 20D (vacuum) 120 20:1 0-50 110 700 5200
120mm 16D 120 16:1 0-50 110 600 5200
90mm 20D (vacuum) 90 20:1 0-55 55 320 3200
90mm 16D 90 16:1 0-55 55 280 3200
75mm 20D (vacuum) 75 20:1 0-55 37 160 1200
75mm 16D 75 16:1 0-55 37 140 1200
50mm 12D 50 12:1 2-70 7.5 50 600
