CNC Pipe End Beveling Machine; High Speed CNC Pipe Beveler

Product Description

Product Description
Fixed-Type High Speed Numerical Control Pipe End Beveling Machine
CNC PIPE END BEVELING MACHINE, CNC PIPE BEVELLING MACHINE
Company Profile
QSPT is professional manufacture company of pipe fabrication machines.. we provide you with pipe beveling/chamfering machine,pipe welding machine, pipe/elbow/flange fitting-up equipment, intelligent pipe warehouse and pipe fabrication line.
Qianshan has partnership with many companies, such as China Oil & Gas, China Petroleum (CNPC/PTR), China Petrochemical (SINOPEC/KSS), China Ocean/Marine/Onshore & Offshore Engineering(CNOOC/CNOEC), China Chemical Engineering (CNCEC), China Nuclear Energy (CNECC), China Thermal Power, China Hydroelectric, China Wind Power, Metallurgy(MCC), China Shipbuilding Industry Corp(CSIC/CSSC), China Aerospace(CASC/CASIC), etc. Its products have been exported in large scale to Southeast Asia, Africa, Europe, America etc.

After Sales Service
Aim of after-sales service: standing in the customers' shoes
Team of after-sales service: Client satisfaction is lowest standard
Site of after-sales service: professional, comprehensive,detailed
promise of after-sales service: to quickly and efficiently resolve all after-sales issues raised by clients without being limited by conditions of costs.

FAQ
Q: Are you trading company or manufacturer ?
A: We are factory based trading company
Q: How long is your delivery time?
A: Generally it is 30-40 days if the goods are in stock. or it is 60-80 days if the goods are not in stock, it is according to quantity.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 40% T/T in advance ,balance before shipment.
If you have another question, pls feel free to contact us.
Performance features
On-line performance: Good(designed as per the on-line equipment of the production line)
Beveling speed: ≤ 5min /pipe bevel (dn200 sch40)
Bevel cutting: Cutting a pipe with other equipment such as band saw and then machining each bevel.
Bevel quality: Very good
Application: For machining the u or v shape bevels for numbers of pipes with heavy wall thickness
Technical parameters
Pipe diameter applicable: Dn50-400(Φ 57-426)/ dn100-600(Φ 114-610)/ dn200-800(Φ 219-813);
Pipe wall thickness applicable: 4-90mm; 6-180mm
Materials applicable: Carbon steel, alloy steel, stainless steel and cryogenic steel, ect.
Bevel shape: U, x, v and double v
Cutting direction: Radial automatic differential cutting feed or axial semi-automatic motor cutting feed(inlet frequency); Radial nc motor cutting feed or axial nc motor cutting feed
Retracting direction: Radial automatic motor retracting or axial automatic motor retracting(inlet frequency); Radial nc motor retracting or axial nc motor retracting
Driven by: Motor
Clamping system: Work piece is clamped by hydraulic cylinder & centering automatically
Bracket system: Screw lifting adjustable
Rev of the principal axis: Stepless speed control & variable frequency
Axial displacement: 80mm(principle axis) 100mm(machine head); 150mm(principal axis), 300mm (machine head)
Bevel angle of tool rest: 0° ~45°
Widthwise displacement: ± 50mm; ± 100mm
Control system: PLC controlling; CNC controlling
Automatic aligning: At the end of beveling machine conveying system equipped with lifting device could be provided if necessary to adjust automatically the center elevation of the pipe, so as to bevel the pipes with different diameter
Conveying system: End beveling vf conveying systems driven by motor are equipped at front and rear sides of the beveling machine if necessary.

---
