Automatic Aerosol Spray Paint Can Filling Capping Machine Gas

Product Description

IntroductionThis aerosol production line is suitable for the production of snow spray, spray paint, party window spray, rust remover and other internal glass beads/steel beads aerosol products. Also suitable for the production of body spray, air freshener, olive oil spray, shaving spray and other conventional aerosols. The machine can produce 2400-3600 cans per hour; With high filling precision, high efficiency characteristics. The whole line machine is equipped with explosion-proof device, which can be applied to various diameter aerosol tanks and various types of nozzles and outer covers.
Features : 1) Aerosol filling machine, in the design of the contents will be semi-automatic filling machine, semi-automatic sealing machine, semi-automatic filling machine propellant (including booster pump) combined with the completion of a work platform, and can be any single work. Any two machine interaction work, can be adjusted.
2) Contents of various liquid filling machine for filling medium has good self-priming function. Contains a certain viscosity and concentration of media (such as paints, polyurethane foam sealant for black and white material); semi-automatic sealing machine sealing quality and reliable, and easy to install, larger cylinder seal, the gas pressure 0.25-0.3MPa when the source can also be sealed ; semi-automatic filling machine mainly used for propellant
3) In the filling (c butane gas, Freon, dimethyl ether and 134a, etc.) no corrosion can be liquefied. Main seals are imported. Applicable to all kinds of aerosol filling valve. Booster pump with large capacity two-way booster. So filling fast, accurate.
4) The machine small footprint, simple operation. A worker can only complete the whole process of production (labor intensity of production with other domestic manufacturers of semi-automatic sealing machine operator rather), is the preferred aerosol manufacturers.
5) The design of this machine, all the pneumatic valves are used the national standard pneumatic valves, and all the open design, easy to replace, easy to buy.
6) The production line has been widely used in food, medicine, health, automotive, environment, fire and aerosol cosmetic products packaging supplies, such as: mousse, hair spray, air fresheners, insecticides, disinfectants, fire extinguishing agents, carburetor cleaner ....
7) The equipment for a single month of thousands of small and medium manufacturers can use.
Product Parameters
MAIN PARAMETERS :

Technical Parameters Product capacity 2400-3600cans/h Single luqid fillling head capacity 10-250ml Total liquid filling capacity (three heads) 10-750ml Single gas filling head capacity 10-250ml Total gas filling capacity 10-750ml Filling tolerance ≤±1% Applicable valve 1" standard valve Crimping diameter 26.5-28mm Crimping depth 4.5.5.5mm Applicable can diameter 35-70mm Applicable can height 70-330mm Max. comprssed air consumption 3M3/min Compressed air working pressure 0.6-0.7Mpa

Detailed Photos
Intelligent control panel and touch screen
control panel
Working parameters can be set easily without the need to train operators, which helps improve work efficiency. Operation panel language can be customized in different languages, if you need, please contact us. Bottle Feeding TableVariable speed bottle feeding table is the basic feeding system of aerosol spray bottle filling line, operator will put empty bottles on the table, with gear motor driving, the bottle will be arranged to the conveyor, the machine will be able to work with different size bottle. Liquid Filling MachineThis machine adopts position pump, which is suitable for different kinds liquids, with high filling speed and high filling precision. The pump uses quick-fit removal structure: easy cleaning and disinfection. The filling nozzles adopt anti-drip and anti-drawing filling device. The machine adopts PLC and human-computer touch screen control systemSpray Valve feeding machine
This valve putting part worked with stable speed and high efficiency. The machine adopts PLC and human-computer touch screen control system. The valve sorter and feeding parts can be easy to change for the different size.Spray Valve Sealing MachineThe sealing head is specially designed according to valve. When sealing the bottle, first step press valve to position it, then sealing claw will seal the bottle. The air proof circle inside the valve will tightly linked to the bottle, so it is beautiful without leakage.Spray Head Pressing MachineThe vibrating cap feeder will arrange the spray heads automatically, sending the caps to the production line from the pipe under the air power. It can save labors and increase productivity. Product Application
After Sales Service
FAQ
Q1: Are you manufacturer?A1: Yes, we are the manufacturer of mixer and filling lines over 15 year's experience.
Q2:How can I know your machine has good quality?
A2:We will send video of the machine working condition, video chatting see our workshop and also you can come to visit our factory.
Q3:What is your advantage?
A3: 1)Competitive price; 2)Excellent technical support;3)Great after-sale service; 4)Over 15 years experience
Q4:What is the payment terms?
A4:30% deposit, the balance before delivery.
Q5:How long of the delivery time?
A5: Normally 40-50 working days depend on the detail machine you request.
Q6:What is your warranty time?
A6:One year. Life-long maintenance services and technical support.
Q7:Can you offer overseas service?
A7: Yes, if request.We suggest online problem solving firstly, if the problem still shows we can arrange engineer to go to your factory to solve the issue.

---
