1. specification
2. Application
It is suitable for the flat printing of glass, CD, nameplate, self-adhesive, credit card, ceramic paper, wooden toy puzzle and electronic industry PCB, SMT solder paste, film switch, etc. It is also suitable for the flat printing of products with high overprinting precision based on gold and silver Paper card, metal sheet, PVC and so on.
3. Technology parameter
1. Microcomputer control each function action, high degree of automation
| 14. The mesh plate quick lifting device makes it quick and convenient to change the mesh plate
|
2. Automatic four-digit counter to count the number of prints
| 15. with long suction and automatic suction function
|
3. Fully cast aluminum body, with metal painting on the surface
| 16. The Angle of scraper and reinker can be adjusted
|
4. Double-column lifting structure, stable and precise height
| 17. Pneumatic mode: panel/foot switch
|
5. Left and right stroke can be adjusted
| 18.Left and right drive mode: pneumatic
|
6.Equipped with high-quality buffer to eliminate printing vibration
| 19. Up and down drive mode: pneumatic
|
7.Constant pressure device of scraper ensures stable pressure during printing
| 20. Scraper pressure control: constant pressure with pressure regulating valve
|
8. up and down stroke:150mm
| 21. Left and right stroke：500mm
|
9. The position of the frame can be adjusted front and back, left and right, and horizontally
| 22. Table front and back, left and right, rotation Angle fine turning
|
10. Suction stainless steel table, adsorption of various film products
| 23.Action mode : fully automatic/semi-automatic/manual
|
11. scraping size :10*50mm
| 24. Maximum height of the plate：150mm
|
12. The machine running speed is fast, stable, low noise
| 25.Work plate area:500*700mm
|
13.Original high quality components, quality assurance
| 26. Maximum frame size：500*950mm
|
