10*6LHD Truck Mounted Concrete Pump Hb67V 67m Self-Loading Concrete Mixer

Product Description

Product Description
1. The adoption of new multi-section boom design optimized by bionic technology effectively reduces placing blind zone and better adapts to placing in high-rise and narrow space.2. On the basis of the design concept of high rigidity structure, simulative calculation and testing of full-work-condition loading make chassis structure deformation smaller and overall work stability higher.3. Based on laser guide, coaxial assembly makes piston head's moving track more precise, with smaller resistance and higher efficiency.4. Germany's hydraulic technology quintessence truly realizes fully-hydraulic reversing, in which self-adaption control in fully-hydraulic closed-loop is realized, with no need for any electrical components, more effective, steadier and zero pollution.

Detailed Photos
Product Parameters

Category	Item	Unit	HB67V
Overall	Outline dimension	mm	15780*2500*4000
	Overall weight	kg	53000
Chassis	Model	-	Actros 5046E5
	Wheelbase	mm	2020+5180+1350+1450
	Max.power	kW	335
	Emission standard	-	China V
Pumping system	Theoretical	m³/h	170
	Concrete pumping pressure	MPa	8
	Theoretical pumping times	Times/min	21~23
	Delivery cylinder diameter x stroke	mm	φ260×2000
Placing boom	Reach height	m	66.1
	Reach depth	m	48.6
	Slewing radius	m	60.9
	Slewing angle	°	±270
Others	Transfer tuble	-	Rock valve
