Plastic Injection Motorcycle Tail Box Mould

US$20,000.00-40,000.00 1 Set (MOQ)

Basic Info.

Model NO.

J1811054

Mould Cavity

Single Cavity

Plastic Material

Process Combination Type

Single-Process Mode

Application

Commodity, Motorcycle

Runner

Hot Runner

Design Software

AutoCAD

Installation

Fixed

Certification

ISO

Standard

DME

Customized

Size

According to Customers Requirement

Mould Quality Control

Professional QC in House

Mould Runner System

Hot or Cold Runner System

Mould Standard

Dme, Hasco, Lkm, etc

Mould Design Software

Ug, Proe, Solidworks CAD, Ect

Mould Cooling System

by Experienced Designer

Mould Operating Mode

Automatically by CNC

Mould Base

S50c,Lkm,Hasco

Heat Treatment

Nitriding

Time of Warranty

1 Year

Transport Package

High Qulity Wooden Case

Specification

DME, HASCO, LKM, etc

Trademark

JSLMOULD

Origin

Huangyan, Taizhou, China

HS Code

8480719090

Production Capacity

300sets/Year

Product Description

Motorcycle tail box mould
1. Provide 3D design
2. Mould steel/hardness: P20 HRC28-32
3. OEM service
4. Mould life: 500, 000shots
JSL Mould Quality Control
For the Q/C of mould, there are 3 steps:
1. Mould Material Q/C
- Mould Steel Checking(Hardness, flaw detection)
- Mould Standard Spare Parts Checking(hardness, size, flaw checking)
2. Mould Making Process Q/C
- design checking (part design, mould design, mould engineering drawing)
- checking each part of mould's size after machining, according to 2D drawing
- mould testing(check mould running condition)
3. Check with customer's requirement again before mould shipping.

Product Name	Plastic Injection Motorcycle Tail Box Mould
Product material	PP
Core& Cavity Steel	718
Steel hardness:	HRC34-38
Mould Standard	DME, HASCO, LKM, etc
Cavity Number	ONE
Injection System	Direct Gate, Point gate, etc
Ejector System	Ejector Plate, Ejector Pin, etc
mould base	S50C
Cycle Time	45-50S
Tooling lead time	60DAYS
Mould life	1, 000, 000SHOTS
Quality assurance	ISO9001
Specification	According to client' s requirements

Our Advantage	1. High quality
	2. Reasonable price
	3. On time delivery
	4. Good After-sale service
	5. Strict quality control
	6. All the mould are automotic.

Offer you	In-time response on letters, telephone calls or fax
	In-time supply the quotation and mould designs
	In-time communication on the technical points
	In-time sending pictures for the mould machining progress and mould finishing schedule
	In-time mould test and sample delivery
	In-time mould delivery.
motorcycle tail box mould
1. Samples/Drawing & Requirement from you
2. Mould design: we will Communicate& Exchange the opinion with you after you place order.
3. Material Purchase: Steel cutting and Mould base tooling.
4. Assembling.
5. Inspection of mould: following and controlling the tooling processing.
6. Mould testing: We will inform you the date. Than will send the sample' s inspection report& injection parameters with the sample to you!
7. Your instruction & confirmation for shipment.
8. Ready made mould before packing.

For more information please contact us.
