PE Plastic Recycling Machine with Enhanced Washing Line for Granulating Process

Product Description

State-of-the-Art Plastic Recycling Washing Line: Engineered by Wenzhou Wandun Machinery Co., Ltd., this PE Plastic Recycling Machine with Enhanced Washing Line is designed for unparalleled efficiency in the granulating process. Experience superior performance and reliability tailored to meet your plastic recycling needs.
Product Description
The plastic recycling washing system is a cornerstone of Kitech machinery's recycling series. This ingeniously designed, modular system is tailored to handle rigid plastics and bottles. It efficiently processes various types of plastics such as PE, LDPE, HDPE, PC, PS, and ABS, ensuring optimal soft recycling.
Kitech offers customizable module combinations designed to meet your specific requirements and material conditions. With the capability to handle a wide range of raw materials, Kitech provides production lines ranging from 300 to 10,000 Kg. Choose from economy to high-level configurations to match your production needs.

Introduction:

Type	WT500	WT100	WT2000	WT3000
Capacity(kg/h)	400-500	800-1000	1600-2000	2500-300
Dimension(L*W*H)	35*10*5	50*12*6	70*12*6	120*20*6
Steam consumption(kg/h)	0-150	0-200	0-300	0-600
Chemical consumption(kg/h)	0-3	0-5	0-10	0-20
Energy consumption(kwh)	175	198	306	550
instalation power(kwh)	210	330	498	810
*** (person /shift)	3-5	3-8	3-10	3-12

Main Technical Variables:
Belt conveyor:
Heavy-duty type, equipped with a gear motor;
Side walls designed to prevent material spillage;
Crusher:
Precisely engineered, the blades are sharp and powerful;
Enclosed cutting chamber to contain materials;
Externally adjustable knives for ease of use;
Shredder:
Specially designed hopper to prevent material ejection;
Four-way rotating knives with unique holders;
Extremely robust pedestal bearing housings;
External mounting of bearing pedestal designs;
Screw conveyor:
Constructed with wear-resistant stainless steel screws;
Triple sealing with external bearing design;
Washing tank:
Double station discharge valve positioned at the bottom;
Variable speed control via inverter;
Heavy-duty washing unit, enabling separation of materials with different densities;
Friction washer:
Rotor and blades made from wear-resistant steel;
Rotor with dynamic balance treatment, achieving an accuracy of ±3-5g;
Active material washing to safeguard downstream units;
Centrifugal dryer:
Rotor with dynamic balance treatment, ensuring an accuracy of ±3-5g;
Mild circular screen designed in a four-piece polygon configuration;
The washer/dryer housing is constructed with stainless steel welded construction;
Squeezing dryer:
Heavy-duty shaft and blade;
Double hydraulic press units;
Motorized screw squeezing;
Hot air pipe dryer:
Pipeline constructed with stainless steel welding;
All material-contacting parts are stainless steel;
Hot air drying system for efficient drying;
Storage buffer:
Directly connected with the pelletizing process;
Large storage capacity for uninterrupted operation;
Electrical cabinet
Equipped with international brand low voltage components;
Double circuit safety relay for enhanced protection;
Intelligent and modular PLC controlling system for seamless operation.

Q1. What are your terms of packing?
A: Our standard packaging includes placing the machine on a protective pallet and securely wrapping it with plastic film to ensure safe transportation.
For exports to European countries, we ensure the wooden boxes are thoroughly fumigated for safe and compliant transport. We meticulously pack using PE film, and we also offer customized packing solutions tailored to meet the unique requirements of our esteemed customers.
We are equipped and prepared to accommodate special requests to meet your specific needs and preferences.
Q2. What are your payment terms?
A: Our payment terms are straightforward: we require a 30% deposit via T/T, with the remaining 70% due before delivery. To ensure transparency, we provide detailed photos of the products and their packaging before the final payment is made.
Q3. What are your delivery terms?
A: We offer flexible delivery terms including EXW, FOB, CFR, and CIF to accommodate your logistical needs.
Q4. What is your delivery timeframe?
A: Generally, our delivery timeframe is between 30 to 60 days following receipt of your advance payment. The exact time may vary depending on the specific items and quantities in your order.
Delivery times are flexible and may vary based on the specific details and specifications of your order.
Q5. Do you test all your products before delivery?
A: Absolutely, we perform a comprehensive 100% test on all our products to ensure they meet our high-quality standards before delivery.
Q6: How do you ensure long-term and positive business relationships?
A: 1. We consistently deliver high-quality products at competitive prices to provide maximum value for our customers.
2. We treat every customer with the utmost respect, building genuine and lasting business relationships and friendships, regardless of their background or origin.

---
