Our Advantages 1. 15 years old company, focus on button switch production, factory strength
2. Sufficient inventory and fast delivery
3. Product certificate complete, excellent quality
| Dimension | 29mm*13mm*35mm |
| Contact Feature | Form | 1NO,1NC,1NO+1NC,2NO,2NC,2NO+2NC |
| Rated load | 8A/12A |
| Max switching voltage | 250VAC/30VDC |
| Contact resistance | ≤50mΩ |
| Material | Ag Alloy |
| Electrical life | ≥1*105 |
| Mechanical life | ≥1*107 |
| Operate voltage (25ºC) | DC:≤75% Rated voltage, AC:≤80% Rated voltage |
| Release voltage (25ºC) | DC:≤10% Rated voltage, AC:≤30% Rated voltage |
| Maximum voltage (25ºC) | 110% Rated voltage |
| Coil voltage | DC12-24V, AC110-220V (Other voltages can be customized) |
| Coil power | DC: 0.53W, AC: 1.0VA |
| Pick-up time | ≤20ms |
| Release time | ≤20ms |
| Dielectric strength | Between contacts | 1000VAC/1min(leakage current 1mA) |
| Between contacts(different pole) | 1000VAC/1min(leakage current 1mA) |
| Between contacts and coil | 5000VAC/1min(leakage current 1mA) |
| Insulation resistance | ≥1000mΩ(500VDC) |
| Ambient temperature | -40 ~ +55ºC |
| Ambient humidity | 35%-80%RH |
| Atmospheric pressure | 86-106KPa |
| Shock resistance | 10G (sinusoidal half-wave pulse: 11ms) |
| Vibration resistance | 10-55Hz (double amplitude: 1.0mm) |
| Installation | PCB or Socket with DIN Rail |
| Weight | Approx. 17g/PCS |
