Product Details
Product Description
Product Description
Product Description
Pellet/Column Activated Carbon
*made of high-quality anthracite coal ,tar oil
*refined by advanced technology and equipment.
*highly developed hole structure and prodigious surface area provided maximum volume activity which shows good adsorption
capacity.
In addition, coal columnar activated carbon pellets also has some special functions, such as removing VOC,methane, chlorine,
ammonia, nitrogen, benzene, formaldehyde, SO2 and Co,etc.,
Pelletized Catalytic Activated CarbonCatalytic carbon retains all the adsorption characteristics of conventional activated carbons, but combines them with the ability to promote chemical reactions. In addition to concentrating reactants via adsorption, the catalytic carbon promotes their chemical conversion.
Catalytic Activity
Not Impregnated
Improved Trace Organic Capacity
High Hardness
Works at Low Oxidant Levels
Simple Equipment Design
Reduced Carbon Requirements
Enhanced Performance
No safety concerns with exotherms or toxicity
Reduced fines and handling losses
Wide applicability; can eliminate chemical addition
Reliable; Reduces operating costs
Details Images
if you want to know more details of the pellet activated carbon,welcome contact us to get the videos and datas1. High adsorption efficiency: Pillar activated carbon has a large specific surface area and developed pore structure, and can efficiently adsorb pollutants in gases, such as volatile organic compounds (VOCs), odorous substances and harmful gases. 2. Low resistance: The columnar structure allows air or other gases to pass through with less resistance. It is especially suitable for occasions that require continuous ventilation and can reduce fan energy consumption. 3. Longer service life: Compared with powdered or granular activated carbon, columnar activated carbon has high physical strength, is not easily broken, and is resistant to wear and tear, so it is more durable and requires less frequent replacement. 4. Easy to regenerate: When the columnar activated carbon is saturated with adsorption, it can be easily regenerated by heating or chemical methods to regain its adsorption capacity. 5.Flexible and easy operation: the columnar shape is easy to fill and replace, and is suitable for treatment facilities of various sizes.
Product Properties
Carbon Substrate
| Impregnated Carbon
|
Particle Type:
| Pelletized
| Bulk Density, g/cc:
| 0.55 (min)
|
Typical Particle Size, (Diameter), mm:
| 4mm
| Moisture, %:
| 15 (max)
|
CCl4 Activity, %:
| 60 (min)
| Wear rate,%
| 1.9 (max)
|
Iodine Number, mg/g:
| 1000 (min)
| Hydrogen sulfide breakthrough
capacity, gH2S/cc carbon:
| 0.14 (min)
|
Surface Area, m2/g:
| 1050 (min)
|
Hardness, %:
| 95 (min)
|
Note:
Proper clothing and respirator must be utilized when regenerating carbon with water.
Confined space/low oxygen procedures should arranged before entry,as wet activated carbon removes oxygen from air,it will cause a serious hazard to workers inside carbon operation vessels
Application
1. Industrial emission treatment: used in chemical, petrochemical, pharmaceutical manufacturing and other industries to treat emissions containing VOCs, sulfides, ammonia and other harmful gases to protect the environment and meet emission standards. 2. Indoor air purification: Pillar activated carbon is widely used in air purifiers in homes and public places to remove harmful substances and odors in the air and improve air quality. 3. Respiratory protective equipment: used to manufacture the poison filter layer in industrial and masks to protect personnel from toxic gases, chemical warfare agents, etc. 4. Deodorization treatment: Used to control and reduce odor problems in places where odor is prone to occur, such as garbage disposal stations and sewage treatment plants. 5. Purification of biogas: In the production and application of biomass energy, it is used to remove impurities such as hydrogen sulfide and carbon dioxide in biogas and improve the energy utilization efficiency of gas. 6. Air purification stations and vehicle air purification: used in urban air purification stations and car air purifiers to reduce the impact of air pollutants on human health.
>>
