| US$150.00-160.00 | 1 Piece (MOQ) |
| Application | 1. Vending machine 2. Telemetry, SCADA 3. Vehicle logistics and diagnostics controlling 4. Parking meter and Taxi Monitoring 5. Telecom equipment supervision (Mobile base station, microwave or optical relay station) 6. Remote Data Monitor and Control 7. CCTV, security surveillance 8. Water, gas and oil flow metering and schedule 9. AMR (automatic meter reading) 10. Power station monitoring and control 11. Remote POS (point of sale) terminals, ATM, 12. Traffic signals monitor and control, Traffic info guidance 12. Oil field, weather forecast, environmental protection, street lamp monitoring and control 13. Early Warning of Mountain Torrent 14. Fleet management 15. Power distribution network supervision 16. Central heating system supervision 17. Weather station data transmission 18. Hydrologic data acquisition 19. Bus/Car/Vehicle WiFi hotspot |
Wireless Specification | 1. Use high-powered industrial ,Multiple frequency bands wireless 3G/4G modem. 2. Support WCDMA/HSPA/HSPA+/EV-DO and GPRS, EDGE, CDMA 1X |
Hardware System | 1. Industrial high-powered 32bits MIPS 2, 300M 2. FLASH: 4MB (Extendable to 16MB) 3. SDRAM: 16MB (Extendable to 64MB) 4. E2PROM: 64KB 5. Interface: 10/100M Ethernet Port RS232 serial port (Support RS422/RS485 if needed), rates: 110~230400bits/s Indicator lights: "Power", "Online", "Alarm", "System", "Link/ACT" Antenna interface: Standard SMA female interface, 50 ohm SIM/UIM interface: Standard user card interface Power interface: Standard 3-PIN power jack Reset button: Restore the router to its original factory default settings 6. Power supply: Standard power supply: DC 12V/1.5A Power range: DC 5~35V 7. Wireless module: High-powered industrial module 8. Size: Outline dimension: 150X102X25.5mm 9. Weight: 530 g 10. Others: Operation temperature: -35~+75º C Storage temperature: -40~+85º C Humidity: 95% (unfreezing) |
| Software function | 1. Support VPN client(PPTP, L2TP, IPSEC and GRE) 2. Support auto recovery mechanism, including online detect, auto redial when offline to make router always online 3. Support firewall and packet filter 4. Support multi protocols, such as TCP/IP, UDP, ICMP, SMTP, HTTP, POP3, OICQ, TELNET, FTP, SNMP, etc. 5. Support dynamic and static route IP 6. Support DHCP server 7. Support NAT, such as SNAT, DNAT etc. 8. Support dynamic DNS (DDNS) 9. Support DMZ host 10. Support route transmission, data communication by serial port. Support data service center management 11. Support VPN/VPDN network 12. Support WEB configure (local and remote) 13. Support telnet management and console 14. Support switch interface to make multi terminals sharing router's wan connection. 15. Support multi WAN dial method, including auto allocated IP, specifying local IP, specifying local and remote IP 16. Can be used as PPP server. Support multi authentication method, such as PAP, CHAP, CHAP-MS, CHAP-MSV2. 17. Support multi debug method, such as web, console debug and SYSLOG etc. 18. Support firmware upgrade by console 19. Support firmware upgrade by TFTP 20. Support online/offline trigger control by SMS, telephone ring and data from COM and ethernet port. 21. Support multi OS, such as WINDOWS, LINUX, SCO UNIX etc |
| Enhanced function: (optional) | 1. Support low-consumption mode, including sleep mode, scheduled online/offline mode, scheduled power-on/power-off mode 2. Support remote firmware upgrade. 3. Support M2M management platform(parameter configuration, status monitoring, remote upgrade) 4. Support WAN port. Support wired and wireless network mutual backups 5. Can be extended to support extended double module/double SIM 6. Can enlarge storage equipment (small M2M managed server) 7. Can be extended to support 4 G LTE(FDD-LTE,TD-LTE)modem 8. Can be extended to support single module/double SIM 9. Support Wi-Fi IEEE802.11 b/g/n 150Mbps 10. Support DTU and GPS optional 11. Support customized |
Cellular | |
| 4G(FDD LTE/TDD LTE) | AU: B1/B3/B5/B7/B8/B28, B40 EU: B1/B3/B7/B8/B20/B28/B31, B38/B40 US: B2/B4/B5/B13/B17/B25, B41 JP: B1/B3/B8/B9/B18/B19/B21/B28, B41 CN: B1/B3, B38/B39/B40/B41 |
| 3G(UMTS/WCDMA/HSDPA/HSUPA/HSPA+) | 850/900/1900/2100 MHz 850/1900/2100 MHz 900/2100 MHz |
| 2G(EDGE/GPRS/CDMA/EVDO) | 850/900/1800/1900 MHz |
Antenna Interface | |
| Number of ports | 1 or 2 (MAIN + AUX/WiFi/GPS) |
SIM | 1 or 2(3 V & 1.8 V) |
Ethernet Interface | |
| Number of ports | 5 x 10/100 Mbps, 5 LAN or 4 LAN + 1 WAN |
| Magnet isolation protection | 1.5 KV |
Serial Interface | |
| Number of ports | 1 x RS-232 or 1 x RS-485 |
| Baud rate | 300bps to 230400bps |
Software | |
| VPN tunnel | PPTP/L2TP, IPsec, GRE, OpenVPN |
| Firewall | DMZ, NAT, Filtering (IP/MAC/Port/Url/Access/Domain name) |
| Management | Web, CLI/Telnet Command, M2M management platform optional, SSH optional, SMS optional |
| Serial port | Transparent, TCP Client/Server, UDP, Modbus RTU |
Others | |
| Reset button | 1 x RST |
| LED indicators | 2 x NET, 4 x LAN, 1 x WAN, 1 x WLAN |
| Power | 5 to 32 V DC(standard 12V/1.5A) |
| Power consumption | Idle: 160 mA@12 V Data link: 220 mA (peak) @12 V |
| Housing & Weight | Metal(IP34), 500 g |
| Dimension | 150 x 102 x 25.5 mm |
| Installation | Desktop, wall mounting and DIN rail mounting |
| Certification | CE, RoHs, FCC |
