| Model | A4 Standard | A4+CSA | A4 PLUS | |||||||||
| Load/dimensions | ||||||||||||
| Rated load | 370 kg | 500 kg | 540 kg | |||||||||
| Vehicle weight (lead-acid battery) | 580 kg | 600 kg | 610 kg | |||||||||
| Vehicle weight (lithium battery) | 448 kg | 468 kg | 478 kg | |||||||||
| Total length | 3190 mm | 3740 mm | 3500 mm | |||||||||
| Total width | 1190 mm | 1190 mm | 1190 mm | |||||||||
| Total height | 1900 mm | 1900 mm | 1900 mm | |||||||||
| Number of passengers | 4 people | 4 people | 6 people | |||||||||
| Minimum ground clearance | 120 mm | 120 mm | 120 mm | |||||||||
| Wheelbase | 2453 mm | 2453 mm | 2453 mm | |||||||||
| Front/rear wheel track | 880 mm/ 970 mm | 880 mm/ 970 mm | 880 mm/ 970 mm | |||||||||
| Tires | 18x8.5-8 (6-ply rated high-quality tire) | 18x8.5-8 (6-ply rated high-quality tire) | 18x8.5-8 (6-ply rated high-quality tire) | |||||||||
| Power system | ||||||||||||
| Voltage | Motor | Controller | Battery | Charger | ||||||||
| 48V | 5KW | HIO | 6 PCS 8V deep cycle lead-acid batteries/ 105-160Ah lithium battery | HIO onboard charger | ||||||||
| Vehicle performance | ||||||||||||
| Speed range | Range | Turning radius | Steering system | Front suspension | Rear suspension | Braking distance | ||||||
| 8-30km Vehicle color | 80-100km (no load) | 4000mm | Bidirectional push pinion and rack | MacPherson independent suspension | Variable cross-section leaf springs and ≤3400mm | |||||||
| Standard body color | Black, white, ivory, turquoise, wormwood green, forest green, sky blue, electric blue, orange, Dior red | |||||||||||
| Standard seat color Vehicle configuration | Beige | |||||||||||
| Standard configuration | 48V-AC system Using HIO independently developed onboard charger AC 5KW motor | |||||||||||
Optional configuration | Optional battery (lead-acid battery, lithium battery) Optional speed meter Optional electromagnetic parking brake Optional luxury seats and luxury steering wheel Optional LCD screen | Optional aluminum alloy wheels (8 inches, 10 inches, 12 inches) Wireless charger Optional light kit(turn signals, headlights, driving lights) Vehicle start-stop system Front basket | ||||||||||
