Large Space 400kg Silent Stainless Hot Sale Vvvf Control Lift Passenger Elevator

Product Description

Large Space 400kg Silent Stainless Hot Sale Vvvf Control Lift Passenger Elevator
Product Description
1. Small Machine Room Passenger Elevator Lift

With Machine Room
Loading ( Kgs)	Person	Speed ( m/s)	Roping	Shaft Clear Inner Size ( W*D in mm)	Car Clear Inner Size ( W*D*H in mm)	Door Open ( W*H in mm)	Pit Depth ( mm)	Overhead Heigh
450	6	1.00	2:1	1800W*1650D	1200W*1000D*2250H	800W*2100H	≥1500	≥4200
		1.50					≥1600	≥4400
		1.75					≥1700	≥4500
630	8	1.00	2:1	2000W*1750D	1400W*1100D*2250H	800W*2100H	≥1500	≥4200
		1.50					≥1600	≥4400
		1.75					≥1700	≥4500
800	10	1.00	2:1	2000W*2000D	1400W*1350D*2250H	800W*2100H	≥1500	≥4200
		1.50					≥1600	≥4400
		1.75					≥1700	≥4500
1000	13	1.00	2:1	2200W*2050D	1600W*1400D*2250H	900W*2100H	≥1500	≥4200
		1.50					≥1600	≥4400
		1.75					≥1700	≥4500

2. Machine roomless passenger lift elevator

Machine Roomless
Loading ( Kgs)	Person	Speed ( m/s)	Roping	Shaft Clear Inner Size ( W*D in mm)	Car Clear Inner Size ( W*D*H in mm)	Door Open ( W*H in mm)	Pit Depth ( mm)	Overhead Heigh
450	6	1.00	2:1	1800W*1700D	1000W*1200D*2250H	800W*2100H	≥1500	≥4400
		1.50					≥1600	≥4600
		1.75					≥1700	≥4700
630	8	1.00	2:1	2000W*1800D	1100W*1400D*2250H	800W*2100H	≥1500	≥4400
		1.50					≥1600	≥4600
		1.75					≥1700	≥4700
800	10	1.00	2:1	2200W*1800D	1350W*1400D*2250H	800W*2100H	≥1500	≥4400
		1.50					≥1600	≥4600
		1.75					≥1700	≥4700
1000	13	1.00	2:1	2250W*2000D	1400W*1600D*2250H	900W*2100H	≥1500	≥4400
		1.50					≥1600	≥4600
		1.75					≥1700	≥4700

Product Optional Main Product Catalog
Company Profile
World Exhibition Packaging & Shipping
FAQ 1. who are we?
We are based in jiangsu, China, start from 2009,sell to Eastern Europe,Northern Europe,Southern Europe,South America,Western Europe,Mid East. There are total about 301-500 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Household elevator,elevator,Lifting platform,sightseeing lift
4. why should you buy from us not from other suppliers?
We are a professional enterprise focusing on elevator manufacturing, R & D, installation and maintenance. It produces traction elevators, foode elevators, sightseeing elevators, freight elevators, etc. its products cover the world
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian

---
