| US$180,000.00-220,000.00 | 1 sets (MOQ) |
| Complete vehicle parameters | |
| Overall length | 13900mm |
| Overall width | 2550mm |
| Overall height | 4000mm |
| Total weight | 46000kg |
| Pumping system parameters | |
| Theoretical concrete displacement low pressure | 180m³/h |
| Theoretical concrete displacement high pressure | 125m³/h |
| Theoretical pumping pressure low pressure | 8.3Mpa |
| Theoretical pumping pressure high pressure | 13Mpa |
| Theoretical pumping times low pressure | 29 |
| Theoretical pumping times high pressure | 19 |
| Inner diameter of conveying cylinder | 260mm |
| Stroke of conveying cylinder | 2100mm |
| Hydraulic system | open |
| System oil pressure | 32Mpa |
| Oil tank volume | 780L |
| Water tank volume | 700L |
| Conveying pipe diameter | 125mm |
| Length of hose at end | 3m |
| End hose diameter | 125mm |
| Chassis parameters | |
| Chassis brand | sany |
| Chassis model | SYM5460THB1F |
| Engine model | D13C6-480E0 |
| Maximum net engine power | 348/1900kW/rpm |
| Emission standard | National VI |
| Fuel tank volume | 600L |
| Displacement | 12.94L |
| Max speech | 90km/h |
| Key parameters | |
| Number of bridges | 4 |
| Chassis | sany |
| Vertical height of boom | 59.1m |
