| Main Features | Ultra 4K HD Support 4K Ultra HD with super resolution up to 4K@30fps/25fps encoding output, and down compatible with 1080p,720p. USB 3.0 Full functional USB, 3.0 connection,power supply,video and audio all in one and support 2 streaming USB video signal(option) and one auido source. Lens Wide angle up to 84°(support autofocus)/120°. At the same time, it supports EPTZ to make it more biger and visible. Built in Microphone Built in microphone array,omnidirectional pickup, pickup distance up to 12 meters, noise suppressing algorithm with excelent sound. WDR Support WDR, can handle different lighting environmemt. Low Light Star-level ultra-high noise ratio of the new CMOS image sensor can effectively reduce the low noise in the case of image noise, while the application of 2D and 3D noise reduction algorithm, significantly reducing the image noise, even under low light conditions, still keep the picture Clean and clear, the image signal to noise ratio up to 55dB or more. Easy Installation Equiped with damping rotary shaft bracket, to meet the market almost 100% of the display, easy to install, stable and reliable. |
| Camera | |
| Sensor | 1/2.5'', CMOS, Effective Pixel: 8.29M |
| Scanning Mode | Progressive |
| Lens Mount | M12 |
| Lens 1(Default) | Focus: f=3.5mm, FOV: 84° |
| Lens 2 | Focus: f=2.8mm, FOV: 120° |
| Autofocus | Support(84°) |
| Minimal Illumination | 0.5 Lux @ (F1.8, AGC ON) |
| Shutter | 1/30s ~ 1/10000s |
| White Balance | Auto, Indoor, Outdoor, One Push, Manual |
| Camera bracket | bracket with damper |
| Digital Noise Reduction | 2D,3D digital noise reduction |
| Backlight Compensation | Support |
| USB Features | |
| Operate System | Windows® 7 (1080p and under only), Windows 8.1, Windows 10 or higher macOS™ 10.10 or higher Google™ Chromebook™ Version 29.0.1547.70 or higher Linux |
| 2.4 GHz Intel® Core 2 Duo processor or higher 2 GB RAM or more USB 2.0 port (USB 3.0 required for 4K) | |
| Color System / Compression | H.264 / MJPEG/YUY2/NV12 |
| Video Format | 4k@30fps/25fps, 1080p@30fps/25fps, 720p@30fps/25fps, 960x540p@30fps/25fps, 640x360p@30fps/25fps etc |
| USB Video Communication Protocol | UVC 1.0 |
| UVC PTZ | Support(EPTZ) |
| Input/Output Interface | |
| USB Interface | 1xUSB 3.0: Type B, famale |
| General specification | |
| Input Voltage | 5V (USB power supply) |
| Current Consumption | 600mA(MAX) |
| Operating Temperature | -10°C ~ 40°C (14°F ~ 104°F) |
| Storage Temperature | -40°C ~ 60°C (-40°F ~ 140°F) |
| Power Consumption | 3.0W(MAX) |
| Size | 194mm x 34mm x 42mm (without bracket) |
| Net Weight | 0.5KG |
| MTBF | 30000h |
