Basic Info.
Customized
Non-Customized
Gas
Ex, Co, H2s, O2, Nitrogen Dioxide or Other Gases
Type
Catalytic/Electrochemical/Semiconductor/Infrared
Alarm Method
Light/Sound/Vibration
Working Environment
Temperature(-10~55)ºC
Power Supply
Rechargeable Battery
Types of Detection Rays
Y-Ray X-ray Beta-Ray
Battery
3.7V, 1200mA Lithium Battery
Specification
143*77*28mm
Product Description
Product Description
Single Portable Oxygen O2 Gas Detector 0-30%VOL With Bump Test Function Safety Equipment *We support sample orders to check product quality *We also have wholesale prices, buy more, save more
*Each gas detector could be customized monitoring gas (over 200 types) by changing sensors
*Each gas detector could be customized the enclosures colors
*Just send inquiry to know more
*Just click it to suit all your needs Product Parameters
Product Paramenters
| Battery | 3.7V,1200mA lithium battery |
| Precision | ± 2%FS |
| Combustible gas temperature | -40~70ºC |
| Toxic gas temperature | -20~55ºC |
| Detection principle | catalytic/electrochemical/Infrared |
| Alarm method | Light/sound/Vibration |
| Sampling | Natural diffusion |
| Measurement range | 0-100%LEL, 0-100%VOL, 0~1000 PPM, 0-30%VOL, 0-1000ppm, 0-20PPM etc |
| Measurable gas | EX combustible gases, CO, O2, H2S, NO2, natural gas, Methane, NO, SO2, NH3, H2, or other gases as customer requirments |
| Display mode | LCD displays real-time data and alarm status and detects gas |
| Explosion-proof mark | Ex IB IIB CT3 |
| Response time | T90<20s |
| Charging time | 4h-6h |
Detailed Photos
Can customize detecting gas or shell colors according to every customers demand, any confusions, just click to contact us!
1. Adopt advanced imported sensors
2. With sound, light, vibration and other three alarm modes
3.OLED display can continuously display gas concentration in real time
4. English menu operation mode
5. Real-time temperature display function
6. Strong resistance to electromagnetic and RF interference
7. Use rechargeable polymer lithium battery power supply
8. The shell is made of high-strength anti-seismic material
Multi-gases Choices
Any combustible, flammable, toxic, oxygen, TVOC gas could be detected by the referred detector, for more detailed infos, pls contact us by cilicking this link.
| Measuring gas type | Measuring range | Underreport/overreport |
| Carbon monoxide (CO) | (0~1000/2000)µmol/mol | (24/100)µmol/mol |
| Hydrogen sulfide (H2S) | (0~100) µmol/mol | (10/20) µmol/mol |
| Combustible Gas (EX) | (0~100)%LEL | (25/50)%LEL |
| Oxygen (O2) | (0~30)%VOL | (19.5/23.5)%VOL |
| Ammonia (NH3) | (0~100) µmol/mol | (10/20) µmol/mol |
| Sulfur dioxide (SO2) | (0~100) µmol/mol | (10/20) µmol/mol |
| Benzene (C6H6) | (0~100) µmol/mol | (3/6) µmol/mol |
| Hydrogen (H2) | (0~1000/2000)µmol/mol | (50/100)µmol/mol |
| Chlorine gas (CL2) | (0~100) µmol/mol | (2/5) µmol/mol |
| Nitric oxide (NO) | (0~100) µmol/mol | (10/20) µmol/mol |
| Nitrogen dioxide (NO2) | (0~100) µmol/mol | (10/20) µmol/mol |
| Hydrogen cyanide (HCN) | (0~100) µmol/mol | (2/5) µmol/mol |
| Phosphine (PH3) | (0~10) µmol/mol | (2/5) µmol/mol |
| Hydrogen chloride (HCL) | (0~100) µmol/mol | (5/10) µmol/mol |
| Hydrogen fluoride (HF) | (0~10) µmol/mol | (2/5) µmol/mol |
Applications
Company Profile
Ningxia Nuoke Yinfeng Intelligent Technology Co., Ltd.
Specializing in the development, production, sales and technical services of gas detection instruments Gas detection: Oxygen, various flammable and explosive gases, various toxic and harmful gases, volatile organic compounds (VOC), etc. Applications: Environmental protection, petroleum, chemical, shipbuilding, electric power, papermaking, metallurgy, pharmaceutical, water treatment, food processing, coal, building and other fields of gas detection
FAQ
1.Q:Can I have a sample order to test quality?
A: Yes, we re commend and welcome sample order to test and check before order.
2. Q: Do you offer guarantee for the products?
A: Yes, we offer 1 or 2 years guarantee for the products.
3. Q: If I order big quantity, Can I have a cheaper price?
A: We will reduce the price according to the specific quantity and your requirements for the product.
4.Q: How does your I factory do regarding the quality control?
A: Quality is priority, Our factory has passed ISO 9001 with annual audit.Established a procedure to check products at all stages of the manufacturing process-raw materials, in process materials.validated or tested materials, finished goods.etc.
>>
