DC Brushed Gear Motor 20W 24V Stroke 70mm Adjustable Speed for CNC Machine Actuator

Product Description

What is applications use gear motor?
Electric gear motors are used in various applications that require for high output torque and low output rotation speed.
What is gear motor?
Gear motor is combined electric motor with gear reducer box.
Would you like to be GPG motor wholesaler,dealer,distributor,stockist? GPG motor can improve your business.
Taibang gear motor is ideal drive for all kinds of industrial automation products for both industrial and commercial application.
What you can be provided by us is steady quality products(quite and efficient performance gear motor) and engineering solution.
The main products is induction motor, reversible motor, DC brush gear motor, DC brushless gear motor, CH/CV medium gear motors, planetary gear motor,worm gear motor,right angle solid and hollow shaft gear motor, etc, which used widely in various fields of manufacturing pipelining, transportation, food, medicine, printing, fabric, packing, office, apparatus, entertainment etc, and is the preferred and matched product for automatic machine.
1)The stator is made of high quality low carbon steel seamless steel tube and ferrite permanent magnet. 2)The rotor consists of silicon steel sheet,copper coil,commutator and insulating material,etc. 3)The rotor shaft is made of high performance medium carbon alloy steel and processed by special technics.There are round shaft and gear shaft. 4)The bearing and oil seal is selected from well-known brand to ensure good running performance and sealing effect. 5)The wire is made from high temperature resistant and flame retardant material.
Should you any questions,please feel free to contact Ms Susan Liu directly.
Please leave message or send inquiry.I will be back to you asap.
Model Instruction

Model	Gear Head	Rated Power	Voltage	Ampere	Speed	Torque	Shell Diameter	Motor Height
		W	V	A	r/min	mN.m	mm	08
GDM06-SC	2GN	20	12	3.05	1800	106	Φ55	75
					2200	86.8
			24	1.40	1800	106
					2200	86.8

Reduction Ratio	L1	L2	L3
1:3~1:20	75mm	32mm	107mm
1:25~1:300	75mm	42mm	117mm

FAQ
Q: How about your company?
A:We are gear motor factory located in Wenzhou city of China and established in 1995.We have more than 1200 workers.Our main product is AC micro gear motor 6W to 250W, AC small gear motor 100W to 3700W,brush DC motor 10W to 400W,brushless motor 10W to 750W,drum motor 60W to 3700W ,planetary gearbox , and worm gearbox,etc. Q: How to choose a suitable motor?
A:If you have gear motor pictures or drawings to show us, or you tell us detailed specs like voltage, speed, torque, motor size, working mode of the motor, needed lifetime and noise level etc, please do not hesitate to let us know, then we can suggest suitable motor per your request . Q: Can you make the gear motor with customize specifications ?
Yes, we can customize per your request for the voltage, speed, torque and shaft size and shape. If you need additional wires or cables soldered on the terminal or need to add connectors, or capacitors or EMC we can make it too.
Q: What's your lead time?
A: Usually our regular standard product will need 10-15days, a bit longer for customized products. But we are very flexible on the lead time, it will depend on the specific orders.
Q: What is your MOQ?
A: If delivery by sea ,the minimum order is 100 pieces, if deliver by express, there is no limit.
Q: Do you have the item in stock?
A: I am sorry we do not have the item in stock, All products are made with orders.
Q: How to contact us ?
A: You can send us enquiry .

---
