Industrial wool dewatering machine sheep washing production line processing wool machinery
processing wool machinery brief introduction:
This wool washing machine made of stainless steel,the material is wearable and easy to clean.Opean the door and put the dirty wool into it,add wool cleaner,shut the door,the water will into the machine automatically,select the washing time(usually 40 minutes),the machine will wash the wool very efficiency.
Details:
processing wool machinery main parameter;
Model
| JXGX-50
| JXGX-100
| JXGX-150
|
Max washing capacity
| 50kg
| 100kg
| 150kg
|
Drum size (mm)
| 800*980
| 960*1420
| 1060*1650
|
Power (kw)
| 1.5
| 3
| 4
|
r/m
| 36
| 34
| 33
|
Water consumption(kg)
| 520
| 820
| 1000
|
Steam pressure (Mpa)
| 0.4-0.6
| 0.4-0.6
| 0.4-0.6
|
Dimensions (mm)
| 1750*1200*1500
| 2300*1400*1850
| 2560*1330*1520
|
Weight (kg)
| 900
| 1750
| 1850
|
Wool dewater machine
Details:
Model
| JXSS-600
| JXSS-800
| JXSS-1000
|
Diameter (mm)
| 600
| 800
| 1000
|
High of drum(mm)
| 300
| 340
| 380
|
Speed of drum (r/min)
| 1000
| 910
| 900
|
Motor power(kw)
| 3
| 4
| 5.5
|
Capacity (kg)
| 45
| 80
| 130
|
Weight (kg)
| 450
| 850
| 1300
|
Dimension (mm)
| 1250*1250*700
| 1500*1500*800
| 1800*1800*900
|
Wool drying machine(electrical heating or gas heating)
The wool after dewatering,put them into the drying machine,drying about 40 minutes,the wool come out of the machine will be dry wool,can be packed into bags.
Details:
Model
| JXWA-50
| JXWA-100
| JXWA-150
|
Capacity(kg)
| 50
| 100
| 150
|
Drum dimension(mm)
| 1160*1000
| 1320*1100
| 1600*1160
|
Drum speed (mm)
| 32
| 30
| 27
|
Steam pressure (Mpa)
| 0.4-0.6
| 0.4-0.6
| 0.4-0.6
|
Power (kw)
| 3
| 4.4
| 7.4
|
Dimensions (mm
| 1320*1700*2200
| 1500*1800*2360
| 1720*1900*2000
|
processing wool machinery pictures:
