VR Product Description Details Images
| Processor | Intel Celeron J1900/ Intel Core i5-4200U/Intel Core i7-4500U |
| Memory | Onboard DDR3L 4G memory |
| Storage | support 1*MSATA SSD+1*SATA HDD/SSD+1*M.2 SSD(only for core series) |
| Lan | 2*GbE RJ45 Intel@i211-AT |
| | 3*USB 2.0,1*USB 3.0,inside 1*USB2.0 dongle interface |
| | 2*DB9-RS232/422/485 COM |
| | 2*3-wire RS232/485 COM phoenix terminal |
| | 2*3-wire RS232 COM phoenix terminal |
| Interface Port | 1* Audio line-out |
| | 2*8Ω 1W Speak out(optional) |
| | 1*phoenix terminal DC 9-36V Input |
| | 1*AT/ATX Switch |
| | 1*HD output |
| | 1*14bit GPIO(Optional) |
| WIFI | 1x full height Mini PCI-E,onboard SIM slot, support 3G/4G |
| Resolution | 16.2M Color, 1280*800 ( 1280*600 optional) |
| Panel | TFT LCD (support 10.1" 12.1" 15.1" 17") |
| Backlight Hour | (LED )30,000 |
| Brightness | 400cd/m² |
| Visual | -85~85°(H) -85~85°(V) |
| Type | 5 wire resistance type |
| Dimen | 289.53*192.44*48.3MM(for 10.1") |
| Weight | NW: 2.7KG, GW: 4.5kg(10.1" weight, also support 12.1" 15") |
Product Usage HYSTOU Panel PC Company Introduction Hystou is a professional manufacturer and exporter of desktop mini PC. OEM and ODM orders are welcomed. The more you purchase, the cheaper the price. Our company in Shenzhen Welcome to visit our factory! Workers are assembling mini pc. Packing&Shipping Packing List: Normally we use the carton box, 5 or 10pcs per carton 1 x Panel PC 1 x Power adapter(correct power plug based on buyer's country) 1 x VESA bracket(some model not support) 1 x Sata power cable and data cable.(some model just support one Msata) 1 x Warranty card & user manual FAQ
