Automatic Bolt Straightening Machine with Straightness Detection

Product Description

Automatic Bolt Straightening Machine With straightness detection The straightening machine is specially used for all kinds of shafts.
After quenching and bending deformation need to straighten the parts.
Through the hyperbolic principle of extrusion to achieve the straightening effect.
The processing object is all kinds of bars, bolts, shafts and other parts.
Straightening machine equipment can meet the customer's needs for straightening, feeding, receiving, no trace after straightening.
To a large extent have improved the level of automation of machinery and equipment and processing capacity, but also greatly reduces the consumption of equipment and the cost of late maintenance.
It is an indispensable equipment in production and processing.

Product Parameters

Items		Unit	HZ-40	HZ-63	HZ-100
Nominal force		KN	400	630	1000
Distance of the point of thimble from ram		mm	140	150	160
Max. stroks of ram		mm	200	200	200
Depth of throat		mm	300	300	300
Talbe dimension	B1 L-R	mm	1500	1500	1600
	A1 F-B	mm	450	450	500
Max.diameter of workpiece to be straightened		mm	φ110	φ120	φ150
Speed of ram	Descent	mm/s	32	24	30
	Return	mm/s	60	90	90
Motor power		Kw	4	11	11
Overall dimensions	A	mm	1600	1870	1780
	B	mm	1500	1500	1600
	H	mm	2720	2725	2775
Total weight		Kg	3500	4500	5500

---
