Lzx-CNC-800 Automatic Copy Router 3 Axis CNC Machine for Aluminium Profile Drilling and Milling/Aluminum Copy Routing Milling Machine

Product Description

Product Description
LZX-CNC-800 is a 3-axis cnc copy router which is used for automatic processing of lock hole and slot,water drain slots and hinge holes on pvc and aluminum windows and doors.
Main Features
1. Applicable material: pvc,aluminum profile2. X,Y,Z three axis with servo-feed,fully automatic processing.3. Programming is easy,graphics library for selecting the appropriate hole type and setting the size.4. The worktable can be turned over on three sides at 0 degrees, 90 degrees and -90 degrees which is friendly for 3 sides processing.5. Automatic coolant spraying.
6. Length can be customized.
Specification

Power supply	AC 380V 50Hz	Z-Travel	280mm
Input power	5.75kw	Processing range	100×120mm
Type	milling machine	Handle type	ER20
Speed of mainshaft	18000r/min	Suitable material	aluminum profile,PVC
Working air pressure	0.5-0.6Mpa	Size(long×width×high)	1600*1500*1950mm
X-Travel	800mm	Weight	500Kg
Y-Travel	300mm

Details Images

Hisena CNC,since 2008
Our Team
Our Customers

FAQ
• Are you factory or trading company?
We are a factory with more than 10 years experience in manufacturing door and window equipmen
• What kind of payment methods do you have?
We support T/T and L/C payment.
• Do you have customized service?
Yes, we can do customized order.
• How about shipping time and method?
The delivery time of our regular stock machines is 10-15 days, and the shipping method is mainly by sea. Small machines, tools and accessories can be shipped by air.
• How long is the service life and warranty?
The designed service life of our machines can be more than ten years, and all machines have one year warranty except consumables.
• How to install and use the machine after arrival?
Our equipment has been debugged before leaving factory to meet production standard requirements.
We can provide engineers on-site installation training, remote videophone installation guidance, installationand commissioning videos, user manuals and variety methods.
• How to do the maintenance for machine?
Please carry out daily maintenance, monthly and annual maintenance and inspection for the machine according to the requirements in product instruction manual.

---
