Epoxy Resin Vacuum (Pressure) Casting Equipment
Description
This equipment is special for epoxy resin casting dry type transformers, bushings, current transformers, potential transformers, HV switch insulators, arc-distinguish coils and other electric apparatus.
It is applicable for with-stuffing casting and without-stuffing casting.
It is suitable for degassing, mixing and casting high polymer materials under vacuum condition, such as bisphenol-A, outdoor-type epoxy resin, polyurethane, etc.
It is applicable for processing both mixed material with stuffing added by user and double-component pre-mixed stuffing, very flexible.
The equipment system can be added or reduced according to user’s requirements. It can be modularly rigged. It is characterized by convenient installation, easy operation, and high automation.
Main features
- Perfect vacuum system: the whole process is carried out under vacuum condition.
- Reliable metering system: there are two kind of metering methods based on different process requirement:
l Feeding pump + electronic scale (for casting with stuffing)
l Metering pump + static mixer (for casting various kind products)
- Advanced and safe heating technology:
l Mixing tank is heated by , good temperature uniformity, high precision temperature control
l Casting tank is heated directly by electric heating plate
- Advanced & reliable metering and control system: controlled by computer, key process and those easy to be mis-operated are controlled interlocked; Process revising, process curve recording, process parameter adjusting, can be achieved by computer very conveniently. The whole metering control and vacuum control are all full pre-set automatic.
Equipment Classification
-- Basic type vacuum (pressure) casting equipment
-- Dynamic mixing type vacuum (pressure) casting equipment
-- Static mixing type vacuum (pressure) casting equipment
Main Technical Data:
Effective size of the casting tank: 2400×3000mm(customized)
Final material mixing tank: 300L
Max. effective mould size: 1400×2000mm
Magnitude of partial discharge of the casting: ≤10PC
Annual production capacity:1,000,000KVA
Main component of the machine
300L resin mixing & degassing system……....................................1 set
300L hardener mixing & degassing system……..............................1 set
Electronic scale system…….............................................................2 sets
300L final material mixing system…….............................................1 set
Vacuum casting tank system…….....................................................1 set
Heating system……..........................................................................4 sets
Vacuum pump system……................................................................2 sets
Pneumatic pipeline system…….........................................................1 set
Material feeding system……..............................................................1 set
Electrical controlling system……........................................................1 set
Steel frame platform…........................................................................1 set
>>
