X-ray Luggage Metal Detector Small Tunnel Size Use for Hotel/Airport

Product Description

General Specification
x-ray luggage scanner
x-ray baggage scanner
Airport x ray scanner
security x ray machine
x-ray screening machine
luggage scanner
baggage scanner
x-ray security scanner
airport x-ray scanner
baggage scanning system
airport baggage scanner
luggage x-ray machine
airport x ray machines
* Tunnel Size: 500(W)*300(H)mm
* Conveyor Speed: 0.22m/s
* Conveyor Max Load: 150kg
* Wire Resolution: 38AWG
* Penetration: 8mm Steel
* Film Safety: Guarantee ISO1600 Film
* X-ray Leakage: <0.2 μ Gy/h (at a distance of 5cm From external housing)
X-ray Generator
* Generate direct: Upward
* Generate angle: 60 degree
* Anode Voltage: 80Kv
* Anode power: 0.6mA
Cooling / Duty Cycle: Oil Cooling /100%
Image System
* X-ray Sensor: L-Shaped Photodiode Array (monoenergetic), 12bit Deep
* Monitor: High Resolution Color, LCD Accord, 17 inch
* Image Processing: Edge enhancement, image strengthening, image lightening, , reducing darkening,
Image returning, image retrieval.
* Image Grey Level: 4096
* Image Max Resolution: 1024 * 1280 pixel
* Image Processing: 24bit for processing real time
* Image storage: Storage 60000 pictures in real time
* Zoom: 32 Times Enlarge, Whole screen continuous observation
Installation Data
Operation temperature/Humidity: 0-45º C/20%-95%(non-condensing)
Storage Temperature/Humidity: -20º C-60º C/20%-95%(non-condensing)
Operation Power: 220VAC(± 10%)50± 3Hz
Power Consumption: 0.8KVA
Noise: <65dB

Tunnel Size:	500(W)*300(H)mm
Conveyor Speed:	0.22m/s
Conveyor Max Load:	100kgs
Dose per Inspection:	<2.9 μGy/h
Resolution:	<0.101mm Metal Wire
Penetration:	8mm Steel
Film Safety:	Guarantee ISO1600 Film
X-ray Leakage:	<0.05 μGy/h (at a distance of 5cm From external housing)
Generate direct:	Upward
Generate angle:	60 degree
Anode Voltage:	70Kv
Anode power:	0.4 to 0.5mA
Cooling / Duty Cycle:	Oil Cooling /100%
X-ray Sensor:	L-Shaped Photodiode Array (mono-energetic), 12bit Deep
Monitor:	High Resolution Color, LCD Accord, 17 inch
Image Processing:	Edge enhancement, image strengthening, image lightening, reducing darkening, image returning, image retrieval.
Image Grey Level:	4096
Image Max Resolution:	1024 * 1280 pixel
Image Processing:	24bit for processing real time
Image storage:	Storage 60000 pictures in real time
Zones & Zoom:	1-9 Image regions, 2, 4, 8, 16 Times Enlarge, Whole screen continuous observation
Operation temperature/Humidity:	0ºC-45ºC/20%-95%(non-condensing)
Storage Temperature/Humidity:	-20ºC-60ºC/20%-95%(non-condensing)
Operation Power:	220VAC(±10%)50±3Hz
Power Consumption:	1.0 KW (max), 0.3KW(working)
Noise:	<65db

---
