HD3105m-24 Mini Lathe, Metal Lathe Machine, Turning Center Professional Grade Machinery

Product Description

Product Description
- Robust box guideways designed for heavy-duty cutting, ensuring unparalleled stability and precision.
- A 30-degree slanted one-piece bed structure enhances high rigidity, providing superior support during operations.
- Stabilized Unit Structure expertly crafted to minimize thermal displacement, ensuring consistent performance.
- Integrated processing capabilities with synchronized control of the main spindle for seamless operations.
-- Experience multi-tasking efficiency with our advanced wedge type BMT turret, enhancing productivity.
Outstanding rapid traverse rate: 30m/min (Z-axis) for swift and efficient movements.
- Ergonomically designed for easy access to chuck and tool, maximizing user convenience.
Product Parameters

Description			Unit	HD3105M
Capacity	Swing over bed		mm	Φ740
	Swing over front door		mm	Φ640
	Swing over saddle*		mm	Φ480
	Max. turning diameter		mm
	Max. turning length		mm	672
	Bar workiing diameter		mm	Φ740
Travels	Travel distance	X-axis	mm	260
		Z-axis	mm	730
Feedarates	Rapid traverse	X-axis	m/min(ipm)	24
		Z-axis	m/min(ipm)	30
Spindle	Spindle speed(Belt Type)		r/min	2,800
	Spindle nose			A2-8
	Spindle through hole diameter		mm	Φ91
	Min. spindle indexing angle(C-axis)		deg	0.001
Turret	No. of tool stations		st	12
	OD tool size		mm	25
	Boring bar diameter		mm	50
	Indexing time(1st swivel time)		s	0.15
	Rotary tool spindle speed		r/min	4000
Tail stock	Quill diameter		mm	Φ100
	Quill bore taper(Live)			MT5
	Compressed air supply		mm	120
Motors	Main spindle motor		kW(Hp)	15/18.5
	Collant pump motor		kW(Hp)	3.7
Power source	Electric power supply(Rated capacity)		kVA	35
Machine size	Machine height		mm	1755
	Machine dimension	length	mm	3284 3285
		width	mm	1817
	Machine weight		kg(lb)	5800

ALL-IN-ONE TYPE OF BED
Optimal Structural Analysis
The structural analysis incorporated in the machine's design significantly enhances the tool post body while reducing the machine's height. This ensures the bed maintains dynamic rigidity even during the most demanding heavy-duty cutting tasks.
The HD-SY Series features a 30-degree bed slope, providing exceptional stability for precision machining.
Integrated Coolant Tank
Designed with a front-mounted coolant tank for enhanced convenience. Easy chip removal from the right side boosts operational efficiency.
Box Guideway
Every axis in the HD-SY Series is equipped with box guideways, optimizing travel ability. These guideways excel in dampening vibrations from heavy-duty cutting, ensuring smooth operations.
Sealed GIB Structure
The X-axis in the HD Series is engineered with a sealed GIB structure to protect the turcite from chip damage, extending the machine's lifespan.
Rapid Traverse Rate (X/Z)
HD 3105M achieves a rapid traverse rate of 24/30 m/min, ensuring swift and efficient operation.
Travel (X/Z)
HD 3105M provides a travel range of 260/730 mm, offering versatility in machining tasks.
Mill Turret
The BMT turret's robust design secures tools with four bolts and a key on the mounting surface, offering high reliability in rigidity and precision for demanding tasks.
Mill Tool Holder
Enhanced machining capabilities with straight and angular milling head tool holders, enabling side machining and I.D. operations with ease.
Suzhou Wugan Intelligent Equipment Co., Ltd. excels in crafting high-performance CNC lathes and turning centres, leveraging the latest international lathe technologies. With a focus on high rigidity, precision, and productivity, coupled with an exquisite design, our machines deliver exceptional cutting performance. Meeting diverse customer needs, we offer high-performance mill-turn combined models for an all-in-one solution, capable of turning, milling, and drilling, enhancing product output and versatility for diverse processing requirements.

---
