Bending machines (WC67YK-125/2500) Hydrualic sheet bending machine price

Product Description

Bending machines (WC67YK-125/2500) Hydraulic sheet bending machine Product Description

The main performance characteristics:
1. Adopt all steel welded structure, with sufficient strength and rigidity.
2. Hydraulic drive, the cylinder at both ends of the machine is placed on the slider, the direct drive sliding work.
3. Sliding block synchronization mechanism is forced to synchronize with the torsion axis.
4. Mechanical block mechanism, stable and reliable.
5. Slider stroke, rapid adjustment, manual adjustment, counter display.
6. Oblique wedge type bending compensation mechanism, in order to ensure the higher bending precision.
Application:
This equipment is the main processing machinery spare parts, in Car, ship, etc. of large equipment bring into play important role in the processing, ships and so on. , in addition to the market sales of many bending parts and the equipment production. Product Parameters Product main technical parameters:

Specification	Nominal Pressure	Length of working table	Distance between uprights	Throat depth	Ram stroke	Motor power
	KN	mm	mm	mm	mm	KW
WC67Y40/2000	400	2000	1700	200	100	4
WC67Y40/2200	400	2200	1800	200	100	4
WC67Y40/2500	400	2500	1900	200	100	4
WC67Y50/2500	500	2500	1900	200	100	4
WC67Y50/3200	500	3200	2500	250	100	4
WC67Y63/2500	630	2500	1900	250	120	5.5
WC67Y63/3200	630	3200	2500	250	120	5.5
WC67Y80/3200	800	3200	2500	250	120	5.5
WC67Y80/4000	800	4000	3000	250	120	5.5
WC67Y100/2500	1000	2500	1900	250	120	7.5
WC67Y100/3200	1000	3200	2500	320	120	7.5
WC67Y100/4000	1000	4000	3000	320	120	7.5
WC67Y100/5000	1000	5000	4000	320	120	7.5
WC67Y125/2500	1250	2500	1900	320	120	7.5
WC67Y125/3200	1250	3200	2500	320	120	7.5
WC67Y125/4000	1250	4000	3000	320	120	7.5
WC67Y125/5000	1250	5000	4000	320	120	7.5
WC67Y160/3200	1600	3200	2500	320	200	11
WC67Y160/4000	1600	4000	3000	320	200	11
WC67Y160/5000	1600	5000	4000	320	200	15
WC67Y160/6000	1600	6000	5000	320	200	15
WC67Y200/3200	2000	3200	2500	320	200	15
WC67Y200/4000	2000	4000	3100	320	200	15
WC67Y200/5000	2000	5000	4000	320	200	15
WC67Y200/6000	2000	6000	4800	320	200	15
WC67Y250/3200	2500	3200	2600	320	250	22
WC67Y250/4000	2500	4000	3200	400	250	22
WC67Y250/5000	2500	5000	4000	400	250	22
WC67Y300/4000	3000	4000	3200	400	250	22
WC67Y300/5000	3000	5000	4000	400	250	22
WC67Y300/6000	3000	6000	4800	400	250	22
WC67Y400/5000	4000	5000	4000	400	250	30
WC67Y400/6000	4000	6000	4800	400	250	37
WC67Y500/6000	5000	6000	4800	400	300	37
WC67Y500/12000	5000	12000	Multi column	400	300	37
WC67Y600/7000	6000	7000	5600	400	300	45
WC67Y700/7000	7000	7000	5600	400	300	45
WC67Y800/6000	8000	8000	5600	500	400	55
WC67Y1000/6000	10000	6000	5600	600	500	75
Description and specifications given in this catalogue are subject to modification without notice

Detailed Photos
Company Information
FAQ
1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
5: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )

---
