Features DigiRock SR2 can test both Rockwell and Superficial Rockwell hardness scales. Manually switch 3kgf and 10kgf initial force, to test rockwell and superficial rockwell scales. Dial reading, resolution is 0.5HR. Motorized loading/dwelling/unloading to make precision force and excellent results.
Applications Rockwell B Scale HRB: Copper alloys, soft steels, aluminum alloys, malleable iron, etc. Rockwell C Scale HRC: Steel, hard cast irons, pearlitic malleable iron, titanium, deep case hardened steel, and other materials harder than B100. Rockwell A Scale HRA: Cemented carbides, thin steel, and shallow case-hardened steel.
| Product Name | Electronic Twin Rockwell Hardness Tester |
| Model | DigiRock SR2 |
| Code# | #811-310 |
| Rockwell Scales | HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRH, HRK,HRL, HRM, HRP, HRR, HRS, HRV |
| Rockwell Force | 60kgf(588.4N),100Kgf(980.7N),150kgf(1471N) |
| Superficial Rockwell Scales | HR15N,HR30N,HR45N,HR15T,HR30T,HR45T HR15W,HR30W,HR45W,HR15X,HR30X,HR45X,HR15Y,HR30Y,HR45Y |
| Superficial Rockwell Force | 15Kgf(147.1N),30Kgf(294.3N),45Kgf(441.3N) |
| Dwell Time | 2-60s Adjustable |
| Reading | Dial Reading |
| Resolution | 0.5HR |
| Loading Control | Motorized loading/dwelling/unloading |
| Max Height of Specimen | 175mm; |
| Throat | 165mm |
| Dimension | 546x182x755mm |
| Packing Dimension | 620x460x870mm |
| Power Supply | AC 220V/50Hz;AC110V/60Hz |
| Gross/net Weight | 90Kg/80Kg |
| Standards | GB/T230.2, JIS Z2245, EN-ISO 6508 , ASTM E-18 |
