Basic Info.
Type
CNC Milling Machining Center
Milling Cutter Structure
All
Automatic Grade
Automatic
Certification
GS, CE, RoHS, ISO 9001
Guideway
Taiwan Linear Guideway
X/Y/Z Axis Travel
400/350/400mm
Transport Package
Wooden Case
Production Capacity
50 Sets Per Month
Product Description
High Speed Bed Type CNC Milling Machining Center Machine For Steel Mold
Model VMC400E
| Items | Unit | VMC400E |
| Table size | mm | 600*350 |
| T slot (No. x distance x width) | no | 3x120x14 |
| Max. load of worktable | kg | 100 |
| X/Y/Z-axis travel | mm | 400/350/400 |
| Spindle nose to table surface | mm | 60-460 |
| Spindle taper | - | BT40 |
| Speed Range | rpm | 40-8000 |
| Spindle motor power | kw | 5.5 servo |
| Cuttiing feed X/Y/Z | mm / min | 2-10000 |
| Rapid feed X/Y/Z | m / min | 30/30/24 |
| Tool magazine capacity | pcs | 16 |
| Tool magazine type | - | Umbrella type |
| Max. tool diameter (full) | mm | 8 |
| Max. tool length | mm | 80/130 |
| Max. tool weight | kg | 300 |
| Tool changing time (tip to tip) | s | 3/7 |
| Positioning accuracy | mm | ±0.005/300JIS |
| Repeat positioning accuracy | mm | ±0.003 JIS |
| Overall dimensions(LxWxH) | mm | 3020*1950*2380 |
| Packing size | mm | 2390*2250*2260 |
| N.W./G.W. | kg | 2400/2600 |
Standard accessories:
GSK CNC controller
Taiwan spindle BT40-120-10000RPM (highest speed 8000rpm)
X,Y,Z Taiwan linear guide ways
16 Tools umbrella type tool magazine
Taiwan high precision ball screws
spindle blowing chip removal system
spindle front seal
Germany FAG bearings
Auto centralized lubrication system
two water cooling,
one air cooling,
electrical hand wheel (MPG),
working lamp
alarm light,
rigid tapping
air gun
Optional accessories:
Arm type automatic tool changer 16 tools
The 4th axis raroty table
Chip removal system with flushing
Renishaw tool setting device
BT40-120 direct connection spindle 10000 rpm(highest speed 8000 rpm)
Oil cooling
Schneider electric
Heat exchanger
>>
