Small Stone Crusher Machine with ISO Certificate

Product Description

Small Stone Crusher Machine With ISO Certificate
1. Stone Crusher Machine Working Principle:
In the process of large stones crushed into small ones, the first-step crusher is called primary crusher. The stone crusher machine(jaw crusher) is one of the most common use and hardest one.The materials are fed into crushing cavity from the top, and then forced to the cavity wall by the jaw tooth which is driven by the eccentric shaft throughout the frame, and crushed into smaller stones. The eccentric movement is normally made by the fly wheels fixed on both ends of the shaft. The roller bearings in support of the flywheels and eccentricity must bear the large impact load, abrasive sewage, and high temperature. In spite of that, the jaw crusher can work reliably, which is the key link for guaranteeing the production efficiency.

2. Stone Crusher Machine(Jaw Crusher) Technical Parameter:

Modle	Max feed size (mm)	Discharged size (mm)	Capacity (t/h)	Power (kw)	Weight (t)
PE150×250	125	10-40	1-3	5.5	0.8
PE200×300	180	20-70	2-8	11	1.4
PE250×400	210	20-80	5-20	15	3
PE400×600	350	40-100	15-60	30	6.5
PE500×750	425	50-100	40-110	55	11.3
PE600×900	480	65-160	90-150	75	17.625
PE750×1060	630	80-160	100-250	90-110	27.5
PE900×1200	750	95-165	120-300	110-160	52
PE1000×1200	850	110-260	180-350	110-160	57
PE1200×1500	1020	150-300	300-500	180-220	100

Note: This specification is just reference; any changes are object to the products. Any other detailed information, please be free to contact to us.

3. Stone Crusher Machine produced by ZK CORP company:

---
