| US$3,500.00-5,200.00 | 3 Pieces (MOQ) |
| Model | BY800 |
| Engine | Honda GX390 13HP gasoline/B&S/Kama Diesel |
| Type | Hydra-static |
| Operative weight kgs(lbs) | 800 (1762) |
| Max travel speed km/h(mph) | 0-4.8(0-3.0) |
| Transmission | |
| Hydraulic pump | 2 x variable displ. |
| Flow Vmin(gpm) | 2 x 32.4 (2 x 8.5) |
| Hydraulic motors | 2 x orbital |
| Brake parking | Mechanical |
| Hydraulic system | |
| Hydraulic pump | Piston pump |
| Flow Vmin(gpm) | 1 x 13.5 (1 x 3.5) |
| Hi-flow Vmin(gpm) | 1 x 22 (1 x 3.5) |
| Max pressure bar(psi) | 150 (2180) |
| Main valve | 2-3 way |
| Cooled system | air-cooled |
| Skip tipping system | Hydraulic |
| Tracks | |
| Standard track width mm(in) | 180 (7.1) |
| Track roller | 3 |
| Rocking rollers | Yes |
| Track tensioning | Yes |
