8 L Automatic Plastic Oil Bottle Extrusion Blow Molding Machine

US$48,000.00 1 Set (MOQ)

Basic Info.

Model NO.
ABLD75II MACHINE
Automation
Automatic
Computerized
Computerized
Certification
CE
Max. Product Volume
5L
Parison Controller
Available
Auto-Deflashing Unit
Available
Station
Double Station
Transport Package
Film Packing
Specification
ISO9001
Trademark
APOLLO
Origin
Zhangjiagang City, Jiangsu Province, China
HS Code
8477301000
Production Capacity
800*2PCS/H

Product Description


ABLB65 full automatic bottle blow molding machine was specially designed for making plastic water bottles, lubricant oil bottles, detergent bottles, cosmetic bottles, and other plastic containers not over 5L.
The features of this machine:
(1)It is suitable for producing PE, HDPE, PP, PVC, PETG, PS so on, plastic containers and bottles in all shapes are available, the max. Product volume is up to 5L.
(2)Single station single die head design, very easy to operate and maintenance.
(3)Most components of the blow moulding machine are from famous world brand.
(4)Fully automatic process with low power consumption, high efficiency, quick and safe operation, easy for maintenance.
(5)Multiple screw available for double layer or tranparent liquid lever line.
(6)Auto deflashing device available, can remove the extra parts of bottles.
(7)Auto lubricant system controlled by PLC.

Max. Product volume
5 liters
Out put capacities 150~180pc/h
Screw diameter 65mm
Screw L/D ratio 24 L/D
Screw drive power 18.5 KW
Screw heating capacity 6 KW
No.of heating zone 3 zones
Output of HDPE 80KG/H
Oil pump drive power 7.5 KW
Clamping force 65KN
Max.size of mold 148-568mm
Mold stroke 330 X 370mm
Max.die diameter 160mm
Blowing pressure 0.6 mpa
Air Volume 0.6 M³/MIN
Cooling water pressure 0.3mpa
Water consumption 50 L/MIN
Size of Machine 3.1x1.5x2.7m
Weight of machine 5.5 ton
