| Model | AN4HBL-2 |
| Structure type | self-propelled, tracked, semi-feeding |
| Size | 4530×1980×2350mm |
| Weight | 2350Kg |
| Power | 33.8kw /46HP |
| Transmission type | (3+1)×2 Mechanical combination |
| Operation gears | low speed 1 or low speed 2 |
| Applicable row spacing | 700~900mm |
| Working rows | Ridge, 2 rows per ridge |
| Operating speed | 1.5~2km/h |
| Depth adjustment range (maximum working depth) | 200mm |
| Loss rate | ≤3.5% |
| Impurity | ≤5.0% |
| Breaking rate | ≤2.0% |
| Picking rate | ≥99% |
| Fuel consumption | 22.5 liters /ha2 |
| Work efficiency | 0.2ha2/h |
