Silicone thermal conductive gap pad 1.25W/mK conductivity TIF200 -50 to 200℃ Temp for LED flood light

Product Details

Product Description

Product Description
Silicone thermal conductive gap pad 1.25W/mK conductivity TIF200 -50 to 200℃ Temp for LED flood light
The TIF™200 Series thermally conductive interface materials are applied to fill the air gaps between the heating elements and the heat dissipation fins or the metal base. Their flexibility and elasticity make them suited to the coating of the very uneven surfaces. Heat can transmit to the metal housing or dissipation plate from the separate elements or even the entire PCB, which in effect enhances the efficiency and life-time of the heat-generating electronic components.
Features
》Good thermal conductive: 1.25 W/mK
》Naturally tacky needing no further adhesive coating
》Soft and Compressible for low stress applications
》Available in varies thickness
Applications
》Cooling components to the chassis of frame
》High speed mass storage drives
》Heat Sinking Housing at LED-lit BLU in LCD
》LED TV and LED-lit lamps
》RDRAM memory modules
》Micro heat pipe thermal solutions
》Automotive engine control units
》Telecommunication hardware
》Handheld portable electronics
》Semiconductor automated test equipment (ATE)

Typical Properties of TIF™200 Series
Product Name	TIF™200-U	TIF™200-E	TIF™200-S	Visual	Composite Thickness		hermal Impedance @10psi (℃-in²/W)
Color	Various			Visual			TIF™200-U	TIF™200-E	TIF™200-S
Construction & Compostion	Ceramic filled silicone rubber			***	12 mils	0.304mm	0.73	0.75	0.76
					20 mils	0.508mm	0.95	0.97	0.98
Specific Gravity	1.75g/cc			ASTM D297	30 mils	0.762mm	1.17	1.18	1.20
					40 mils	1.016mm	1.28	1.30	1.32
Heat Capacity	1 l/g-K			ASTM C351	50 mils	1.270mm	1.47	1.49	1.52
					60 mils	1.524mm	1.68	1.70	1.73
Hardness	15	25	45	ASTM 2240	70 mils	1.778mm	1.86	1.88	1.91
	Shore 00				80 mils	2.032mm	2.05	2.08	2.11
Tensile Strength	425 psi			ASTM D412	90 mils	2.286mm	2.21	2.24	2.28
					100 mils	2.540mm	2.37	2.40	2.44
Continuos Use Temp	-50 to 200℃			***	110 mils	2.794mm	2.49	2.53	2.57
					120 mils	3.048mm	2.65	2.69	2.73
Dielectric Breakdown Voltage	>5500 VAC			ASTM D149	130 mils	3.302mm	2.82	2.86	2.91
					140 mils	3.556mm	2.95	3.00	3.05
Dielectric Constant	5.5 MHz			ASTM D150	150 mils	3.810mm	3.08	3.12	3.17
					160 mils	4.064mm	3.20	3.25	3.30
Volume Resistivity	4.0X10" Ohm-meter			ASTM D257	170 mils	4.318mm	3.34	3.39	3.44
					180 mils	4.572mm	3.44	3.49	3.55
Fire rating	94 V0			equivalent UL	190 mils	4.826mm	3.52	3.57	3.63
					200 mils	5.080mm	3.62	3.68	3.73
Thermal conductivity	1.0 W/m-K			ASTM D5470	Visua l	ASTMD751	ASTM D5470

Standard Thicknesses:
0.010" (0.25mm) 0.020" (0.51mm) 0.030" (0.76mm) 0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm) 0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm) 0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm) 0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm) 0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm) 0.190" (4.83mm) 0.200" (5.08mm)
Consult the factory alternate thickness.
Standard Sheets Sizes:
8" x 16"(203mm x 406mm) 16" x 18"(406mm x 457mm)
TIF™ series Individual die cut shapes can be supplied.
Peressure Sensitive Adhesive:
Request adhesive on one side with "A1" suffix.
Request adhesive on double side with "A2" suffix.
Reinforcement:
TIF™ series sheets type can add with fiberglass reinforced.

---
