New ZOOMLION AS60 Track type Sugarcane Harvester 140KW For Sale
Product Description


Match Commins high-end dedicated high-pressure common rail engine with high horsepower to enable that the power of the whole machine is stronger and the oil consumption is lower.
The unloading is adopted with "rotary" mechanical folding structure, with good operation adaptability, convenient material receiving and more efficiency.
The whole machine is fed by adopting a double drum with 900mm feed inlet in width and 600mm root cutter center distance in width,being applicable for harvesting on double lines with ridge, with higher operation efficiency of the whole machine.
Strong rubber protection and crawling wheel capability of the sugarcane-pressing wheel.
Add a row of fixed knife on both sides of the cage to effectively solve the problem of "wrapping the vine" and reduce the feeding resistance.
The conveying channel is enlarged to 680mm, the feeding amount of the whole machine is larger, the hydraulic motor drives the independent drum, and the conveying capacity is stronger.
The operation efficiency is greatly improved. The working efficiency is 20t/ hour.
Equip a tip cutting device to effectively reduce the impurity-containing rate of the sugarcane harvester.
Through the hydraulic plunger pump, the rotation speed ratio of blower can be stepless and adjustable, and the cleaning effect is better.
Break the design concept of rod-type steering operation for crawler-type harvester in the industry, the patent design for steering wheel operating
is adopted to enable that the steering operation of whole machine is more flexible.
The machine adopts Beidou navigation integration acre measure control system with high precision and efficiency
All system adopting software control with intelligent fault diagnosed
Adopting load-sensitive hydraulic system with auto-control flow distribution to meet dynamic load request and energy saving and reliable.
Hydraulic system heat dissipation independently with control rotate speed of fan and energy saving and lower noise
All electric parts are using Europe and America importing brand. The connectors enjoys reliable quality with waterproof,dustproof and anti-loose
The operation system controlled by CAN bus with easy wiring and reliable information sharing
The sensor control technology which is capable of monitoring machine working state.
The machine walking adopting one-button operation, the diversion controlled by imported steering wheel with comfortable operation.
The great view cab with GR AMMER seat and imported special AC to have comfortable driving.

Model		Unit	AS60
Dimensions(L*W*H)		mm	11500×2200×3630
Weight		kg	9800
Rail distance		mm	1400
Wheel base		mm	2310
Grounding length		mm	1670
Engine	Model	/	High pressure common rail
	Rated power	kW/rpm	140/2050r/min
	Displacement	L	7
	Emission grade	/	GUO
Track width		mm	400
Earthing voltage		kPa	59
Feeding capacity		kg/s	6
Adaptive ridge spacing		mm	≥1100
Adaptive ridge height		mm	0~200
maximum gradability		°	≤20
Operating forward speed		km/h	0~6.65
Qualified rate of cutting height		%	≥90
Root breaking rate		%	≤10
dirt percentage		%	≤8
Total loss rate		%	≤5
Qualified rate of sugarcane section		%	≥93
Fuel consumption per hectare		kg/hm2	190

---
