HBM30 Taladro Vertical Drilling Milling Tapping Cutting Lathe machine

Product Description

Features 1. Gear-driven type.
2. Milling, drilling, boring, reaming.
3. Variable speed.
4. Foot stand is optional.

Specification	Unit	HBM30
Max. Drilling dia.	mm	32
Max.end milling capacity	mm	20
Max.face milling capacity	mm	76
Table size	mm	700 x 210
Table travel	mm	400 x 200
T-slot	mm	3 x 14
Spindle taper		MT3/R8/ISO30
Spindle travel	mm	70
Spindle speed range	r/min	50-2250
Spindle speed step		Variable
Distance from spindle nose to surface of table	mm	210
Distance from spindle nose to table	mm	470
Main motor power	kW	1.5kw(Brushless motor)
Machine dimensions	mm	860*710*1020
Machine weight	kg	220
Hercules Machinery Equipment Ltd.

Standard Accessories:
1. 2-Axis DRO
2. Digital depth ruler
3. Spindle cover with micro switch
4. Drill chuck 3-16/B16
5. Drawbar
6. Arbor MT3/B16-M12
Optional Accessories:
1. Stand
Pictures for reference only:

---
