Rt300CE Crawler Mobile Cone Crushing Plant

Product Description

Product Description The Runtianzhike crawler mobile counter crushing station has a compact and integrated design, with a small construction area. The crushing mainframe adopts new manufacturing technology and unique structural design, which results in a higher crushing ratio and stronger crushing capacity. The processed products are cuboid-shaped, with no tension or cracks, and have a good particle shape. The discharge particle size can be adjusted hydraulically, allowing for diversified crushing specifications. The entire machine is driven by tracks, with strong power and convenient transportation, making it suitable for complex and varied construction environments.
Application scenario: It is widely used in coarse crushing and medium crushing in various medium hardness crushing process.Crushing of all kinds of mine rocks; Highway, railway, water conservancy, electricity, construction and other industriesProduction of sand and stone for construction purposes; All kinds of slag, cave slag, waste asphalt concrete, tailings and waste rock crushing and recycling.
Detailed Photos
Product Parameters

RT300C Crawler Mobile Cone Crushing Plant
Feeding Device	Max feeding Size 210mm
	Feeding Height 3000mm
	Hopper Volume 3m³
	Feeding Capacity 350t/h
Crusher	Crusher Model HP300
	CrusherMotor Power 250kW
Main Corveying Belt	Belt Width B1000mm
	Power 1kW
Mixed Material Corveying Belt	Belt Width B1000mm
	Power 7.5kW
Returned Material Corveying Belt	Belt Width B650mm
	Power 5.5kW
Transmission Corveying Belt	Belt Width B500mm
	Power 3kW
Whole Machine	Total Power 321kW
	Total Weigh 55t
	Working Mode Extemal Power Supply
	Working Dimension 16.4mx4mx5.1m
	Transportation Dimension 18.3mx4mx3.9m

---
